4.2 Device view 1

OUTPUT 4 - 16A
1 2
(1) 19" housing
(2) 16A three-phase current outputs
(3) 32A three-phase current outputs
(4) 63A three-phase current input

4.3 Device view 2

L1
L2
L3
FAULT-CURRENT CIRCUIT
5
(5) Phase control lamps
(6) Fault-current circuit breaker
(7) 3-pole 32A circuit breaker
(8) 3-pole 16A circuit breaker
OUTPUT 3 - 16A OUTPUT 2 - 32A
Fuse OUTPUT 1
6
POWER IN
380-400V ~
50Hz
OUTPUT 1 - 32A
3 4
SB-1200B
Fuse OUTPUT 2 Fuse OUTPUT 3
7
13/16
63A
POWER DISTRIBUTOR
Fuse OUTPUT 4
8
