EN
Before you remove the blade, remove the battery pack.
1. Push the spindle lock button to lock the spindle.
2. Use the hex key to loosen the blade bolt
counterclockwise.
3. Remove the bolt and outer flange.
4. Use the lower guard lever to lift the lower guard and hold
the lever.
5. Remove the blade.
4

OPERATION

Always wear eye protection.
Do not use any attachments or accessories not
recommended by the manufacturer of this product.
4.1

START THE MACHINE

Figure 5
The machine can not work until the lock-off Button is
pushed fully to the left or right. Do not operate the machine
at low speeds for extended periods of time.
1. Pull the trigger to turn the machine ON.
4.2

STOP THE MACHINE

Figure 5.
1. Release the trigger to stop the machine.
4.3

ADJUST THE CUTTING ANGLE

Figure 6.
1. Loosen the bevel lock knob.
2. Use bevel scale to set the necessary angle.
3. Tighten the bevel lock knob.
4.4

ADJUST THE CUTTING DEPTH

Figure 7.
1. Loosen the depth adjustment lever.
2. Raise or lower the base until the depth scale reaches the
required cutting depth.
3. Tighten the depth adjustment lever.
4.5

ADJUST THE CUTTING WIDTH

Figure 8.
NOTE
WARNING
WARNING
NOTE
English
1. Loosen the width adjustment knob to move the edge
guide to the necessary width.
2. Tighten the width adjustment knob after adjustment.
4.6

OPERATE THE MACHINE

Figure 9.
Kickback occurs when the blade stalls quickly and the
machine is driven back to you. A step which pinches the
blade in the wood can cuase blade stalling.
To prevent kickback, release switch trigger immediately if
the blade stalls.
1. Keep the blade at the correct depth position.
2. Examine the workpiece for nails before you cut. Do not
saw into a nail.
3. Make straight cuts. Use a straight edge guide when rip
cutting. This helps prevent you twist the blade.
4. Use clean, sharp, and correctly set blades. Do not make
cuts with blunt blades.
5. Support the workpiece correctly before you begin a cut.
6. Use stable pressure when you make a cut. Do not force a
cut.
7. Do not cut warped or wet lumber.
8. Hold the saw tightly with the two hands and keep your
body in a balanced position to against the forces if
kickback occurs.
5

MAINTENANCE

Do not let brake fluids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can cause damage to the
plastic, and make the plastic unserviceable.
Do not use strong solvents or detergents on the plastic
housing or components.
Remove the battery pack from the machine before
maintenance.
5.1

CLEAN THE MACHINE

The machine must be dry. Humidity can cause risks of
electrical shocks.
• Clear the unwanted material out of the air vent with a
vacuum cleaner.
• Do not spray the air vent or put the air vent in solvents.
6
WARNING
CAUTION
CAUTION
WARNING
CAUTION
