Kühlschrank / Bedienungsanleitung Refrigerator / User Manual KSU50...
Seite 2
Vielen Dank, dass Sie sich für dieses Produkt entschieden haben. Diese Gebrauchsanweisung enthält wichtige Sicherheitshinweise sowie Hinweise zum Gebrauch und der Wartung Ihres Gerätes. Lesen Sie diese Gebrauchsanweisung vor der ersten Benutzung des Geräts aufmerksam durch, und bewahren Sie sie sorgfältig auf. Symbol Bedeutung WARNUNG...
1 SICHERHEITSHINWEISE 1.1 Allgemeine Sicherheitshinweise Bitte lesen Sie diese Gebrauchsanweisung sorgfältig durch. WARNUNG: Die Belüftungsöffnungen am Gerätegehäuse bzw. am Einbaugehäuse stets freihalten. WARNUNG: Den Abtauvorgang nicht mit mechanischen oder anderen Mitteln beschleunigen, die nicht vom Hersteller empfohlen wurden. WARNUNG: Keine elektrischen Geräte in den Lebensmittelfächern des Geräts verwenden, die nicht den Empfehlungen des Herstellers entsprechen.
Seite 5
Kühlelemente nicht beschädigt werden. R600a ist ein umweltfreundliches, natürliches, jedoch explosives Gas. Wenn die Kühlelemente aufgrund von Beschädigungen undicht werden, das Gerät von offenem Feuer und Wärmequellen fernhalten und den Aufstellraum mehrere Minuten gut lüften. • Beim Tragen und Aufstellen des Geräts den Kühlmittelkreislauf nicht beschädigen.
Seite 6
keine solche Steckdose vorhanden ist, muss eine geeignete Steckdose von einem Elektrofachbetrieb installiert werden. • Das Gerät kann von Kindern ab 8 Jahren und von Menschen mit körperlichen, sensorischen oder mentalen Einschränkungen oder ohne Erfahrung und besondere Kenntnisse verwendet werden, sofern sie unter Aufsicht sind oder in die sichere Nutzung des Geräts eingewiesen wurden und die damit verbundenen Gefahren kennen.
Seite 7
• Wenn das Netzkabel beschädigt ist, muss es vom Hersteller, einem Servicebeauftragten oder einer vergleichbar qualifizierten Person ausgetauscht werden, um Gefährdungen zu vermeiden. • Das Gerät ist nicht für die Nutzung in Höhen über 2000 m ausgelegt. Bitte beachten Sie zur Vermeidung einer Lebensmittelkontamination die folgenden Hinweise: •...
1.2 Hinweise zum Aufstellen und mindestens 5 cm betragen. • Wenn die Kühl-Gefrierkombination Anschließen neben einem Tiefkühlgerät steht, Beachten Sie bitte die folgenden Punkte, muss zwischen den beiden Geräten bevor Sie die Kühl-Gefrierkombination zum ein Abstand von mindestens 2 cm ersten Mal verwenden: eingehalten werden, damit sich an der •...
Seite 9
• Die Kühl-Gefrierkombination nicht vermeiden. über ein Verlängerungskabel an das CE-Konformitätserklärung Stromnetz anschließen. Wir bestätigen, dass unsere Produkte • Keine beschädigten, aufgerissenen oder die Anforderungen der anzuwendenden alten Stecker verwenden. Europäischen Verordnungen, Richtlinien • Das Kabel nicht ziehen, knicken oder und Entscheidungen sowie der anderweitig beschädigen.
• Das Gerät ist zur Nutzung im Haus Allgemeine Hinweise: ausgelegt und ausschließlich Fach für frische Lebensmittel (Kühlteil): Die effektivste Energienutzung wird durch zur Lagerung bzw. Kühlung von Lebensmitteln vorgesehen. Es ist nicht die Schubladenanordnung in der unteren für die gewerbliche oder öffentliche Hälfte des Geräts gewährleistet sowie Nutzung konzipiert und nicht für die durch die gleichmäßige Verteilung der...
2.1 Abmessungen Gesamtabmessungen Höhe, Breite und Tiefe des Geräts ohne Griff und Füße. Gesamtplatzbedarf im Einsatz Platzbedarf im Einsatz 1039,0 Höhe, Breite und Tiefe des Geräts einschließlich des Handgriffs, zuzüglich des für die freie Kühlluftzirkulation erforderlichen Höhe, Breite und Tiefe des Geräts Raumes sowie des notwendigen einschließlich des Handgriffs sowie Platzes zum Öffnen der Tür so weit,...
3 VERWENDEN DES GERÄTS Lebensmitteln 3 – 4 : Für die Langzeitlagerung von Anzeige „Tür offen“ Lebensmitteln Die Anzeige „Tür offen“ am Türgriff gibt an, 5 : Maximale Kühlposition. Das Gerät ob die Tür richtig geschlossen wurde oder ist länger in Betrieb. Gegebenenfalls noch offen steht.
Sie während dieser Zeit nicht die Tür Die Darstellungen und und füllen Sie das Gerät nicht mit großen Mengen an Lebensmitteln. Beschreibungen im Abschnitt über Zubehör können je nach Modell von • Eine Verzögerungsfunktion von 5 Minuten Ihrem Gerät abweichen. verhindert Schäden am Kompressor des Kühlgeräts, wenn das Gerät an das Netz angeschlossen bzw.
zum einen von der Anfangsqualität des oder abgedeckt werden, um Feuchtigkeit Produkts ab. Zum anderen ist aber auch und Gerüche zu vermeiden. eine ununterbrochene Kühlkette vor der HINWEIS: Dieses Kühlgerät ist nicht Einlagerung im Kühlschrank ein wichtiges zum Einfrieren von Lebensmitteln Kriterium.
Seite 15
nicht auslaufen. Spezielle Gefrierbeutel, den Gefrierschrank, wenn er vollständig Alufolie, Polyäthylenbeutel und abgetaut ist. Kunststoffbehälter sind dazu am besten • Die auf den Produkten angegebenen geeignet. Volumenangaben beziehen sich immer • Lagern Sie frische Lebensmittel nicht auf die Lebensmittel ohne Verpackung. •...
Seite 16
Maximale Lagerdauer Fleisch und Fisch Vorbereitung (Monate) In Folie wickeln Steak 6 - 8 Lammfleisch In Folie wickeln 6 - 8 In Folie wickeln Kalbsbraten 6 - 8 Kalbsgulasch In kleinen Stücken 6 - 8 Lammgulasch In Stücken 4 - 8 Hackfleisch Verpackt ohne Gewürze 1 - 3...
5.1 Abtauen um den Abtauprozess zu beschleunigen. Entfernen Sie das abgeschabte Eis vom Abtauen des Kühlteils Geräteboden. Zum Entfernen der dünnen Reifschicht brauchen Sie das Gerät nicht abzuschalten. • Um dicke Eisablagerungen zu entfernen, trennen Sie das Gerät vom Stromnetz, lagern Sie das Gefriergut in Kartons um und schlagen sie es in dicke Tücher oder Zeitungspapier ein, damit es...
etwas Natron und trocknen Sie es gut 7 VOR DEM ANRUF BEIM ab. Waschen Sie die ausbaubaren Teile KUNDENDIENST ebenso und bauen Sie sie wieder ein. Schließen Sie das Gerät wieder an das Wenn Sie ein Problem mit Ihrem Stromnetz an und lassen Sie es 2 bis 3 Gerät haben, überprüfen Sie bitte die Stunden auf der Einstellung MAX stehen, folgenden Punkte, bevor Sie sich an den...
Bei einigen Modellen während des • Wenn Sie das Gerät zu anderen als normalen Betriebs des Systems den genannten Zwecken verwenden, aufgrund der Luftzirkulation. übernehmen weder Hersteller noch Händler Verantwortung für eventuelle Die Kanten desGeräts, die mit der Reparaturen oder Störungen während Türfuge in Berührung kommen, sind der Garantiezeit.
Typenschild des Geräts eingeben. Für allgemeine Fragen besuchen Sie die Ausführliche Informationen über das Webseite des technischen Kundendienstes: Energieetikett finden Sie unter dem Link WWW.RESPEKTA.INFO www.theenergylabel.eu. 10 INFORMATIONEN FÜR PRÜFINSTITUTE Installation und Vorbereitung des Geräts für eine eventuelle Ökodesign- Prüfung müssen in Übereinstimmung...
Seite 22
Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
Seite 23
CONTENTS 1 SAFETY INSTRUCTIONS ................24 1.1 General Safety Warnings .....................24 1.2 Installation warnings .....................28 1.3 During Usage........................28 2 DESCRIPTION OF THE APPLIANCE ............30 2.1 Dimensions ........................31 3.1 Thermostat Setting .......................32 3.2 Temperature Settings Warnings ...................32 3.3 Accessories ........................33 3.3.1 Ice Tray (In some models) ..................33 4 FOOD STORAGE ...................
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
Seite 25
natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
Seite 26
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Seite 27
To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
1.2 Installation warnings performance of your fridge freezer. • Clearance of at least 150 mm is required for the first Before using your fridge freezer at the top of your appliance. Do not place time, please pay attention to the following anything on top of your appliance.
Seite 29
high alcohol content vertically in the Packaging and the Environment fridge compartment and make sure their Packaging materials protect tops are tightly closed. your machine from damage that • When removing ice from the ice-making may occur during transportation. compartment, do not touch it. Ice may The packaging materials are cause frost burns and/or cuts.
2 DESCRIPTION OF THE APPLIANCE This appliance is not intended to be used as a built-in appliance. This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. A) Freezer compartment B) Refrigerator compartment 1) Ice box tray 2) Plastic ice scraper *...
2.1 Dimensions Overall dimensions the height, width and depth of the appliance without the handle. Overall space required in use Space required in use 1039,0 the height, width and depth of the appliance including the handle, plus the space necessary for free circulation of the cooling air, plus the height, width and depth of the the space necessary to allow door...
appliance will work longer.If required, “Door Open” Indicator; change the temperature setting. The "Door Open" indicator on the handle shows whether the door has closed If device has SF position: properly or whether it remains open. • Turn the knob to SF to freeze fresh If the indicator is red, the door is still open.
appliance will begin to operate normally refrigerator. Frost tends to concentrate in after 5 minutes. the coldest parts of the evaporating liquid and, in time, your appliance will require • The freezer** of the refrigerator can cool more frequent defrosting. up to -12 °C and more.
• For normal working conditions, it will Maximum How and where to be sufficient to adjust the temperature Food storage time store setting of your refrigerator to +4 °C. Cooked 2 days All shelves • The temperature of the fridge food compartment should be in the range NOTE:...
Seite 35
on the room temperature, the thermostat setting, how often the door is opened, the type of food, and the length of time required to transport the product from the shop to your home. Always follow the instructions printed on the packaging and never exceed the maximum storage life indicated.
Seite 36
Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Lamb meat Wrap in foil 6 - 8 Veal roast Wrap in foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces 4 - 8 In packaging without using spices...
Maximum storage time Vegetables and Fruits Preparation (months) Cut into two pieces and remove the stone Apricot and Peach 4 - 6 Strawberry and Wash and hull 8 - 12 Blackberry Cooked fruits Add 10 % of sugar to the container Plum, cherry, sourberry Wash and hull the stems 8 - 12...
5.1 Defrosting process. Remove all dislodged frost from the cabinet floor. It is not necessary to switch off the appliance for the removal Defrosting the Refrigerator Compartment of thin frost. • For the removal of heavy ice deposits, disconnect the appliance from the mains supply, empty the contents into cardboard boxes and wrap in thick blankets or layers of paper to keep cool.
to the mains supply and leave for 2 to 7 BEFORE CALLING AFTER- 3 hours on setting number MAX before SALES SERVICE introducing the food back into the freezer. If you are experiencing a problem with Replacing LED Lighting your appliance, please check the following To replace any of the LEDs, please contact before contacting the after-sales service.
The edges of the appliance in contact suitable for commercial or common use. with the door joint are warm If the consumer uses the appliance in a way that does not comply with this, we Especially during summer (warm seasons), the surfaces in contact with the door joint emphasise that the manufacturer and the dealer will not be responsible for any...
, the appliance. Visit our website to: See the link www.theenergylabel.eu for WWW.RESPEKTA.INFO detailed information about the energy label. 10 INFORMATION FOR TEST INSTITUTES Appliance for any EcoDesign verification shall be compliant with EN 62552.
Seite 42
NEG-Novex Großhandelsgesellschaft für Elektro- und Haustechnik GmbH Chenover Str. 5 D-67117 Limburgerhof www.respekta.info 52372285...
