Fein ARAD18BCAS Bedienungsanleitung Seite 20

1 609 92A 7AJ • 14.10.22 • T
en
20
– Selecting the radio as the right-hand speaker:
Select from the
menu <Set DSS> → <Right Speaker>.
– Selecting the radio as the left-hand speaker:
Select from the
menu <Set DSS> → <Left Speaker>.
– Switch on the operating mode Bluetooth ® on
the second radio as well.
– Select the other speaker from the menu on the
second radio.
– Control the playback via Bluetooth ® as usual.
Changing Menu Settings
To get to the menu function, press the mute
button (8) (MENU) until the menu function
indicator (e) appears in the display.
Navigating in the menu:
– To scroll through a menu: Turn the source
button (7).
– To select and save a menu setting: Press the
source button (7) (OK).
– To switch to a submenu: Press the source
button (7).
– To switch from a submenu back to a higher
menu: Briefly press the mute button (8). If the
highest menu level has been reached, the ra-
dio will return to audio operation.
To leave the menu function on any level and re-
turn to audio operation, press the mute
button (8) until the menu function indicator (e) in
the display turns off. Alternatively, the radio will
automatically switch back to audio operation
10 seconds after the last press of a button.
If menu settings are no longer being saved when
you switch off the radio, replace the coin cell
(back-up battery).
Menu Options
English
The menu selection is partially dependent on the
audio operating mode of the radio.
Within the menus, the name of each menu is dis-
played on the top line of the multi-function
indicator (j), and the selectable setting on the
bottom line.
<Set EQ>
Sound menu: You can adjust the
treble <Treble> and the bass <Bass> within a
range of –5 to +5. The sound settings are saved
separately for each audio source.
<Set Time>
Time menu:
– You can choose between 24-hour <24 Hour
Mode> and 12-hour <12 Hour Mode> time
formats.
– You can adjust the time manually with <Set
Hour> or <Set Minute>.
– Note: If a radio station that transmits the time
is selected with the DAB/DAB2 audio source,
English
this time is automatically adopted. Manual time
settings will be overwritten.
<Reset All>
Reset menu: You can reset all menu settings to
factory settings <Yes> or return to the current
settings <No>.
<Auto Scan> (with DAB/DAB2 audio source)
Automatic station search menu: You can start
an automatic station search.
<Manual Tune> (with DAB/ DAB2 audio source)
Manual setting menu: You can set the required
frequency manually.
<Display Type> (with DAB/DAB2 audio source)
Display mode menu: You can choose what text
will appear on the bottom line of the multi-func-
tion indicator (j):
– The information broadcast by the radio
station <Dynamic Label>,
– The frequency of the station <Frequency>,
– The signal strength <Signal Strength>,
– The program type broadcast by the radio
station <Program Type>.
<Display Type> (with FM/FM2 audio source)
Display mode menu: You can choose what text
will appear on the bottom line of the multi-func-
tion indicator (j):
– The information broadcast by the radio
station <Radio Text>,
– The station name <Program Service>,
– The program type broadcast by the radio
station <Program Type>.
<Set FM Mono> (with FM/FM2 audio source)
Mono reception menu: You can switch
on <On> or switch off <Off> mono reception.
Mono reception is recommended if the radio of-
ten switches between stereo and mono recep-
tion when a station has poor reception.
<Set DSS> (with Bluetooth ® audio source)
Dual speaker sound menu: You can set the ra-
dio as a right-hand speaker <Right Speaker>, set
it as a left-hand speaker <Left Speaker>, or
switch off the function <OFF>.
Power Supply of External Devices
USB Port
English
The USB port can be used to charge devices that
can be powered via USB (e.g. various mobile
phones). The maximum charging current is 1.2 A.
Open the protective cap of the connector
compartment (15). Using a corresponding USB
cable, connect the USB port of the external
device to the USB charging socket (23) of the ra-
dio (USB charging).
In operation with a rechargeable battery, the ex-
ternal device will only be charged if the radio is
switched on.
English
