Battery model ProCORE18V...
LEDs
5× continuous green light
4× continuous green light
3× continuous green light
2× continuous green light
1× continuous green light
1× flashing green light
Operation with power supply (see
figure A)
English
Use only the power supply listed in the
u
technical data. This is the only this way to en-
sure proper operation of the radio.
Pay attention to the mains voltage. The
u
voltage of the power source must match the
voltage specified on the type plate of the
power supply.
Open the protective cap of the connector
compartment (15). Insert the plug-in
connector (21) of the power supply into the
connection socket (22) (DC IN 18V). Connect
the power supply to the mains supply.
After removing the plug-in connector (21), reat-
tach the protective cap of the connector
compartment (15) to protect against dirt/debris.
Changing the coin cell
To save the time and other settings on the radio,
a coin cell must be inserted as a back-up battery.
Before using the radio for the first time, remove
the protective strip from the inserted coin cell.
Disengage the locking lever (13) of the battery
cover and open the battery cover (12) flap.
If required, remove the rechargeable battery (17).
Pull out the protective strip under the cover (18)
of the coin cell.
Replace the coin cell once the radio no longer
saves the time and the display is getting weaker.
To do this, turn the cover (18) of the coin cell
anticlockwise (e.g. with a coin) and remove the
cover. Insert a new coin cell.
When doing so, ensure that the polarity is correct
according to the illustration on the inside of the
cover (18).
Put the cover (18) of the coin cell back on and
turn it firmly clockwise. The cover is only se-
curely locked if the markings on the cover and
padlock symbol are facing each other.
Take the coin cell out of the radio if you are
u
not using it for a prolonged period of time.
English
Operation
Capacity
u
80−100 %
60−80 %
40−60 %
u
20−40 %
5−20 %
0−5 %
Audio Operation
Switching On and Off
To switch on the radio, press the on/off
button (2). The display (1) is activated and the
audio source that was set the last time the radio
was turned off is played back.
The display (1) is illuminated for a few seconds
each time a button is pressed.
To switch off the radio, press the on/off
button (2) again. The current setting of the audio
source will be saved.
Adjusting the Volume
After the radio is switched on, the volume is al-
ways set to low.
To increase the volume, turn the on/off
button (2) clockwise; to reduce the volume, turn
it anticlockwise.
The volume setting <Volume> will appear in the
display for a few seconds with a value between
English
0 and 30. Before adjusting or changing a radio
station, set the volume to a low setting; before
starting an external audio source, set the volume
to a medium setting.
To switch off the sound, you can briefly press
the mute button (8). To switch on the sound
again, either briefly press the mute button again
or turn the on/off button (2) clockwise.
The volume can be changed at any time. If the
menu function is activated, the display will return
to the menu a few seconds after you have
changed the volume.
The radio switches off automatically after 19 min, if
during this time:
– The volume on the radio is set to 0,
– The radio is muted or
– The volume on the playback device (e.g.
Selecting an Audio Source
To select an audio source, press the source
button (7) until the required internal or external au-
dio source is shown in the display:
– DAB/DAB2: Digital radio via DAB+,
– FM/FM2: Analogue radio via FM,
When stored in the radio for longer periods,
the coin cell can corrode and discharge itself.
English
Protect the radio against direct water con-
tact. Water entering the radio increases the
risk of an electric shock.
Keep the battery cover and the protective
cap of the connector compartment closed
if possible. The closed covers protect the ra-
dio against water and dust.
English
English
English
smartphone) is set to 0.
