Trayless Mobile Rack for 2.5" SATA HDD
1. Model – HDD – Host Interface – Colour
Model HDD
IB-2217aStS 1x 2.5" SATA
2. Package Content
1x IB-2217aStS, 1x SATA cable, 1x power + LED cable, 4x screws, 2x keys, 1x manual
3. Key Features
• 2.5" SATA HDD or SSD in 1x 3.5" bay
• EasySwap – tool less HDD or SSD installation and exchange
®
• Spring for 6 - 9.5 mm HDD height
• Anti-vibration proof up to 3g shock resistance
• Hard disk capacity not limited
• SATA host interface 6.0 Gbit/s
• LED for power and HDD access
• Plug & Play and HotSwap
• Support all operating systems
4. Technical Data
Interface: 1x 15pin SATA power connector
1x 7pin SATA data connector
Material:
Stainless steel/plastic
HDD height: max 9.5 mm
5. Front panel and rear panel
1. Key lock
2. HDD front panel
3. HDD LED indicator
2. 1.
IB-2217aStS
Host Interface
1x SATA
1. SATA power connector (15P)
2. SATA data connector (7P)
3. Access LED connector (4P)
3.
Colour
black
1. 2. 3.
