Mounting Dream MD2619 Installationsanleitung Seite 7

CAUTION:
To avoid potential personal injury or property damage:
All 4 lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate
assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on to
the next step.
To prevent the TV falling down, the Bolt Head Must Keep UP at this step!!
Concrete Wall
Anchor
Solid Concrete Wall Installation
Min.
8"(203mm)
Mounting
Template
3/8"
(10mm)
Bolt Head UP!
6
DANGER
2.5"
(64mm)
Level
