7.3 High-Frequency Emission of Wireless Sensors
A measuring experts certificate of the institute for social
ecological research and education (ECOLOG) has now
confirmed, that the high-fequency emissions of wire-
less keys and sensors based on EnOcean technology
are considerably lower than comparable conventional
keys.
Thus, it is good to know, that conventional keys do also
send electromagnetic fields, due to the contact
spark.The emitted power flux density (W/m²) is 100
times higher than with wireless sensors, considered
over the total frequency range. In addition, a potential
exposition by low-frequency magnet fields, emitted via
the wires, are reduced due to wireless keys. If the radio
emission is compared to other high-frequency sources
in a building, such as DECT-telephones and basis sta-
tions, these systems are 1500 times higher-graded
than wireless keys.
8.

Warranty

Please contact your local dealer for information on cus-
tomer service and warranty conditions.
9. Disposal
The appliance should not be disposed of
with household waste, but should be taken
to your local recycling centre.
10. Conformity
CE-Conformity:2004/108/EG Electromagnetic compatibility
R&TTE 1999/5/EC Radio and Telecommuni-
cations Terminal Equipment Directive
Product safety: 2001/95/EG Produktsicherheit
Standards: ETSI EN 301 489-1: 2001-09
ETSI EN 301 489-3: 2001-11
ETSI EN 61000-6-2: 2002-08
ETSI EN 300 220-3: 2000-09
Product safety: EN 60730-1:2002
The general registration for the radio operation is valid
for all EU-countries as well as for Switzerland.
FCC ID: S3N-SRXX
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired oper-
ation.
Warning: Changes or modifications made to this equip-
ment not expressly approved by Thermokon may void
the FCC authorization to operate this equipment.
www.dimplex.de/en
11.

Technical Data

Geräteabmessungen
50
Technology
Transmitting
frequency
Transmitting range
Temperature
detection
Set point adjustment
Measuring value
detection
Sending interval
Energy generator
Enclosure
Protection
Ambient temperature
Transport
Weight
453322.66.16 · 10/14/B
RTV 101EO, RTF 101EO
Tabelle 3: Technical Data
EnOcean, STM
868,3 MHz
approx. 30m in buildings,
approx. 300m upon free propa-
gation
Range:
Resolution:
Absolute accuracy: typ. +/-0,4K
Range:0...270° angle of rotation
Resolution:1,1°
every 100seconds
every 100seconds
Solar cell, internal goldcap,
maintenance-free
PC, colour pure white
IP20 according to EN60529
-25...65°C
-25...65°C / max. 70%rH, non-
condensed
45 gr.
25
0°C...+40°C
0,15K
EN-7
