Faller 130512 Anleitung Seite 6

Fahrkartenschalter mit anleger

Werbung

6
3/4
Art.-Nr. 180647
liegt nicht bei
not included
non jointe
niet bijgevoegd
P
Q
R
Q
S
Loch mit Ø 2 mm bohren.
Drill hole with a dia. of 2 mm.
Percer un trou avec un diamètrede 2 mm.
Gat met Ø 2 mm boren.
T
Deco 12 + 13
3/8
U
Teile 1/1 zum Bau für niedrige Kaimauer kürzen.
Shorten part 1/1 for building the low quay wall.
Pièce 1/1 pour la construction d'un mur de quai raccourci.
Deel 1/1 voor het maken van een lage kademuur inkorten.
1/1
5 x 5 mm
1/2
S
V
T
11 x 99 mm
2/13
Bemalungshinweis, rot + weiss
Painting instruction, red + white
Instruction de coloration, rouge + blanc
Schilderadviezen, rood + wit
