Dashboard & Power Button
Speedometer
Headlight
Left Direction Indicator Icon
Bluetooth
Temperature Warning
Power Button:
Press the button to power on; press and hold the button for 3 seconds to power off. When the KickScooter is on, press the
button to turn on/off the headlight and the tail light; and press twice to switch between the speed modes.
Speedometer:
It displays the current speed of the scooter, as well as error codes.
Left Direction Indicator Icon:
When this icon blinks, it indicates that the direction indicators on the left side are turned on.
Right Direction Indicator Icon:
When this icon blinks, it indicates that the direction indicators on the right side are turned on.
Walk Mode:
Max. speed is 5 km/h (3.1 mph).
F65I: The headlight and tail light keep flashing and can't be turned off.
F65D: The headlight and tail light are always on and can't be turned off.
* How to enable in the Segway-Ninebot app: Settings > Walk Mode.
Speed Mode:
There are three modes available. The top speed is as follows:
Model
Mode
F65I
ECO (Energy-saving mode)
15 km/h (9.3 mph)
D (Standard mode)
20 km/h (12.4 mph)
S (Sport mode)
25 km/h (15.5 mph)
Error Notification:
It indicates that the scooter has detected an error.
Temperature Warning:
It indicates that the battery temperature has reached 55°C (131°F) or is below 0°C (32°F).
* At this point, the KickScooter cannot accelerate normally and may not be charged. DO NOT use until the temperature has reverted to the
normal range.
Bluetooth:
It indicates that the scooter has been successfully connected to the mobile device.
Battery Level:
The total battery level equals 5 bars.
* The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.
02
Right Direction Indicator Icon
Speed Mode
Walk Mode
Battery Level
Power Button
F65D
15 km/h (9.3 mph)
20 km/h (12.4 mph)
20 km/h (12.4 mph)
Speci cations
2
Item
Parameter
Name
Ninebot KickScooter
Model
F65I
Product
Approx. 1196 × 569 × 1237 mm (47 × 22.4 × 48.7 in)
Length × Width × Height
Approx. 1196 × 569 × 540 mm (47 × 22.4 × 21.3 in)
Folded: Length × Width × Height
Approx. 21.8 kg (48 lbs)
Net Weight
Payload
30–120 kg (66–265 lbs)
Rider
Recommended Age
14–60 years
Required Height
130–200 cm (4'3"–6'6")
Max. Speed
Approx. 25 km/h (15.5 mph)
Typical Range
[1]
Approx. 65 km (40.4 miles)
Max. Slope
Approx. 20%
Bicycle lanes, parks, campuses and most of the flat road conditions and
Traversable Terrain
typical Belgian roads
Machine
Operating Temperature
-10–40°C (14–104°F)
-10–50°C (14–122°F)
Storage Temperature
IP Rating
IPX5
Duration of Charging
Approx. 5 h
Nominal Voltage
46.8 V
Max. Charging Voltage
54.6 V
Charging Temperature
0–45°C (32–113°F)
Battery
Nominal Capacity
12 Ah
Nominal Energy
561 Wh
Over-heating, short circuit, over-current, over-discharge and
Battery Management System
over-charge protection
Nominal Power
0.4 kW, 400 W
Motor
Max. Power
0.7 kW, 700 W
Model
NBW54D603D0D
Type
Built-in
Output Power
0.16 kW, 160 W
Charger
Input Voltage
100–240 V ~ 50–60 Hz, 2.0 A MAX.
Max. Output Voltage
54.6 V
Rated Output
53.5 V
Brake Light
Brighter when braking
Features
Speed Modes
Energy-saving mode, Standard mode and Sport mode
Tire Pressure
40–45 psi
Tire
Tires
10-inch Pneumatic tire
[1]
Typical Range: tested while riding with a full battery, 75 kg (165 lbs) load, 25°C (77°F), at the speed of 18 km/h (11.2 mph) on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
F65D
Approx. 20 km/h (12.4 mph)
, 3 A
