ISY - WOSH - SIMPLY B.
BELLAGIO - SAVOIR
I
ISTRUZIONI PER L'INSTALLAZIONE DELLA RUBINETTERIA
EN
INSTRUCTIONS FOR THE INSTALLATION OF THE FAUCETS
F
INSTRUCTIONS POUR L'INSTALLATION DE LA ROBINETTERIE
D
MONTAGEANLEITUNGEN ZUR INSTALLATION DER ARMATUREN
E
INSTRUCCIONES PARA LA INSTALACION DE LA GRIFERIA
ИНСТРУКЦИИ ПО МОНТАЖУ СМЕСИТЕЛЬНОЙ АРМАТУРЫ
RU
PL
INSTRUKCJE INSTALACJI ARMATURY
ZD4646 / ZD5646 / ZP1646 / ZD3646
ZW5646
ZB2646
ZSA646 / ZSV646
ZSB5646
Zucchetti Rubinetteria S.p.A.
Via Molini di Resiga, 29 - 28024 Gozzano (No) - Italy - Tel. +39 0322 954700 - Fax +39 0322 954823 - zucchettidesign.it
1
Werbung
Verwandte Anleitungen für ZUCCHETTI ZD4646
Inhaltszusammenfassung für ZUCCHETTI ZD4646
- Seite 1 INSTRUCTIONS POUR L’INSTALLATION DE LA ROBINETTERIE MONTAGEANLEITUNGEN ZUR INSTALLATION DER ARMATUREN INSTRUCCIONES PARA LA INSTALACION DE LA GRIFERIA ИНСТРУКЦИИ ПО МОНТАЖУ СМЕСИТЕЛЬНОЙ АРМАТУРЫ INSTRUKCJE INSTALACJI ARMATURY ZD4646 / ZD5646 / ZP1646 / ZD3646 ZW5646 ZB2646 ZSA646 / ZSV646 ZSB5646 Zucchetti Rubinetteria S.p.A.
- Seite 2 INSTALLAZIONE / INSTALLATION...
- Seite 3 INSTALLAZIONE / INSTALLATION 17mm *SOLO VERSIONE RUBINETTO D’ARRESTO *ONLY WITH STOP VALVE VERSION ZP1646 ZD3646 ZD4646 ZD5646 ZSA646 ZW5646 ZSV646 ZB2646 ZSB5646 (mm) 6-11 12-18 19-25 26-32 33-39...
- Seite 4 ZW5646...
- Seite 5 ZD4646 / ZD5646 / ZD3646 / ZP1646 ZB2646...
- Seite 6 ZSA646 / ZSV646...
- Seite 7 ZSB5646...
- Seite 8 Recommended temperat.: 60-65°C Zucchetti taps can be used with electric storage water heathers and instant gas types, centralised system, combi wall-mounted gas boilers and district heating systems. Before connecting the taps we recommend draining the system thoroughly; it is also advisable to install under basin stop valves with filter (art. Z9126P). Should the water pressure be higher than 5 bar, a pressure reducer should be fitted upstream of the supply pipes.
