Qualitätsprodukte aus den Bereichen Wär me, Sanfte Therapie, Blutdruck/Diagnose, Gewicht, Massage und Luft. Bitte lesen Sie diese Gebrauchsanleitung aufmerksam durch, und beachten Sie die Hinweise. Mit freundlicher Empfehlung Ihr Beurer-Team 1. Kennenlernen Arbeitsweise des Bauchmuskel-Gürtels Der Bauchmuskel-Gürtel arbeitet auf Basis der Elektrischen Muskelstimulation (EMS). Der Mus- kelstimulator erzeugt sanfte elektrische Impulse, die über Ihre Haut an die Muskeln weitergeleitet...
All manuals and user guides at all-guides.com Unsachgemäßer Gebrauch – Das Gerät darf nicht angewendet werden: - im Bereich des Kopfes: Hier kann es Krampfanfälle auslösen - im Bereich des Halses / Halsschlagader: Hier kann es einen Herzstillstand auslösen - im Bereich des Rachenraums und Kehlkopfes: Hier kann es Muskelverkrampfungen auslösen, die ein Ersticken herbeiführen können - in der Nähe des Brustkorbes: Hier kann es das Risiko von Herzkammerflimmern erhöhen und einen Herzstillstand herbeiführen...
All manuals and user guides at all-guides.com 3. Gerätebeschreibung Benennung der Teile 1. Bedieneinheit 2. LCD Anzeige 3. Programm- und Sperrtaste 4. Ein / Aus / Pause - Taste 5. Wahltaste Intensität erhöhen 6. Wahltaste Intensität senken 7. Batteriefachdeckel 8. Halterung 9.
All manuals and user guides at all-guides.com Hinweise: – Für dieses Gerät können keine Akkus verwendet werden. – Bei Nichtbenutzen des Gerätes empfehlen wir, das Gerät separat vom Gürtel aufzubewahren. Falls Sie das Gerät über einen längeren Zeitraum nicht benötigen, empfehlen wir zuvor die Batterien zu entfernen.
All manuals and user guides at all-guides.com 5. Anwendung Allgemeines zum Training mit dem Bauchmuskel-Gürtel In der ersten Woche sollten Sie den Bauchmuskel-Gürtel nicht mehr als einmal am Tag anwenden, um Ihre Muskeln langsam an das Gerät zu gewöhnen. Ab dann können Sie öfters trainieren. Hinweis: Zur Regeneration Ihrer Muskeln sollten Sie eine Ruhezeit von mindestens 5 Stunden zwi- schen den Trainingseinheiten einhalten.
All manuals and user guides at all-guides.com Intensitätslevel einstellen Hinweis: Die Intensität kann nur eingestellt werden, wenn die Elektroden Hautkontakt haben. Sie müssen zu Beginn jedes Trainings einen Intensitätslevel einstellen. Drücken Sie die Intensitäts- wahltaste , um die Intensität zu vergrößern und die Intensitätswahltaste , um die Intensität zu verringern.
Kaufes zu führen. Die Garantie ist innerhalb eines Zeitraumes von 3 Jahren ab Kaufdatum gegen- über der Beurer GmbH, Söflinger Straße 218, 89077 Ulm, geltend zu machen. Der Kunde hat im Garantiefall das Recht zur Reparatur der Ware bei unserem eigenen oder bei von uns autorisierten Werkstätten.
All manuals and user guides at all-guides.com use of the abdominal toning belt thus cannot replace actual active training entirely. Electrical muscle stimulation is used for muscle training in the field of sports and fitness to achieve a powerful, slim and attractive body. Application areas include –...
Seite 10
All manuals and user guides at all-guides.com Caution - For your safety ! The device is only designed for use by healthy adults. The device should never be used in the following cases. – users with medical implants (e.g. cardiac pacemaker) –...
Seite 11
All manuals and user guides at all-guides.com Description of the display symbols A Battery status display: flashes if the battery is flat B Intensity: set intensity levels 0 - 40 C Pause symbol: flashes if pause is activated D Timer: remaining time for the program started E Key: key lock is activated...
All manuals and user guides at all-guides.com Where must the belt not be used: – On the head: here it can cause seizures – On the neck / carotid artery: here it can cause cardiac arrest – On the pharynx and larynx: here it can cause muscle spasms, which lead to suffocation –...
Seite 13
All manuals and user guides at all-guides.com Observing the training cycle Each training session consists of three phases: – a warm up phase (30 Hz) of two minutes duration, which prepares the muscles for training – a training phase (at a different frequency depending on the training program) –...
Use mild soapy water or a liquid detergent for this purpose. Do not use bleaches. – The belt is unsuitable for machine washing. 7. Technical Specifications: Model: EM 30 Power supply: 3 x 1.5 V AAA (type LR 03) Electrode size: approx.
All manuals and user guides at all-guides.com 1. Premières expériences Fonctionnement de la ceinture de musculation abdominale La ceinture de musculation abdominale fonctionne sur le principe de stimulation électrique des muscles (EMS). Le stimulateur de muscles produit de légères impulsions électriques que la peau conduit jusqu’aux muscles.
Seite 16
All manuals and user guides at all-guides.com – Gardez l‘appareil à distance des sources de chaleur. – N’utilisez pas l’appareil à proximité d’appareils à ondes courtes ou à micro-ondes (téléphones portables, par ex.), car ils peuvent avoir une influence sur le fonctionnement de l’appareil. –...
Seite 17
All manuals and user guides at all-guides.com 3. Description de l‘appareil Dénomination des parties 1. Unité de réglage 2. Affichage LCD 3. Touche de programme et de verrouillage 4. Touche de marche / arrêt / pause 5. Touche de sélection intensité plus forte 6.
Seite 18
All manuals and user guides at all-guides.com – Retirez le couvercle du compartiment des piles en appuyant et en poussant dans le sens de la flèche. – Introduisez des piles en respectant le repère dans le compartiment des piles. Respectez la polarité correcte des piles. Remarques –...
All manuals and user guides at all-guides.com Quel est l’endroit exclusif où la ceinture peut être utilisée: Mettez la ceinture exclusivement autour du ventre. Le nombril devrait être à moitié recouvert. nombril Arrêt automatique Si l‘appareil n’est pas utilisé après avoir été mis en marche, il s‘arrête automatiquement au bout de 5 minutes.
Seite 20
All manuals and user guides at all-guides.com un certain nombre de cycles d’entraînement. Cependant vous pouvez sélectionner le programme de votre choix en fonction de votre bien-être et de votre niveau de forme physique. Suivre le cycle d’entraînement Chaque séance d’entraînement est composée de trois phases: –...
A cet effet, servez-vous d’eau légèrement savonneuse ou d’une lessive liquide. Ne pas utiliser d’agent blanchissant. – La ceinture ne doit pas être lavée en machine. 7. Données techniques Modèle: EM 30 Alimentation électrique: 3 x 1,5 V AAA (type LR 03) Dimension des électrodes: 10 x 10 cm environ Paramètres (charge 500 ohm):...
Lea atentamente estas instrucciones y observe todas las indicaciones. Atentamente, El equipo Beurer 1. Conocer el aparato Funcionamiento del cinturón estimulador de los músculos abdominales El principio de funcionamiento del cinturón estimulador de los músculos abdominales se basa en una estimulación muscular eléctrica (EMS).
All manuals and user guides at all-guides.com – Utilice usted el aparato únicamente con las piezas accesorias adjuntas. Indicación: En casos poco frecuentes pueden presentarse irritaciones de la piel en la zona de contacto de los electrodos. Utilización inadecuada – En los siguientes casos no debe utilizarse el aparato: - En la zona de la cabeza: aquí...
Seite 24
All manuals and user guides at all-guides.com 3. Descripción del aparato Denominación de las piezas 1. Unidad de funcionamiento 2. Pantalla LCD 3. Botón de programa y de bloqueo 4. Botón Encendido / Apagado / Pausa 5. Botón para aumentar la intensidad 6.
Seite 25
All manuals and user guides at all-guides.com – Coloque las pilas conforme a las marcas del compartimiento de las pilas. Observe que las pilas queden colocadas con la polaridad correcta. Indicaciones: – Para este aparato no es posible utilizar pilas recargables. –...
All manuals and user guides at all-guides.com Lugares en que debe usarse exclusivamente el cinturón: Coloque el cinturón exclusivamente alrededor del abdomen. El ombligo debe quedar cubierto por el centro. Ombligo Desconexión automática Si el aparato no se usara después de conectarlo, se desconectará automáticamente una vez trans- curridos 5 minutos.
Seite 27
All manuals and user guides at all-guides.com culos abdominales está ajustado de manera que pasa automáticamente al siguiente programa de nivel superior, después de un determinado número de ciclos de entrenamiento. Pero usted puede también seleccionar independientemente el programa deseado conforme a su bienestar y a su constitución física.
Nunca utilice blanqueadores. – El cinturón no es apropiado para el lavado a máquina. 7. Datos técnicos: Modelo: EM 30 Alimentación de corriente: 3 x 1,5 V AAA (tipo LR 03) Tamaño de electrodos: aproximadamente 10 x 10 cm Parámetros (carga de 500 ohmios):...
La preghiamo di leggere attentamente le presenti istruzioni per l’uso e di rispettare le avvertenze riportate. Cordiali saluti Il vostro team Beurer 1. Note introduttive Funzionamento della cintura per addominali La cintura per addominali funziona sulla base della stimolazione elettrica dei muscoli (EMS).
All manuals and user guides at all-guides.com Uso improprio - L’apparecchio non deve essere utilizzato nei seguenti casi: - nella zona della testa: pericolo di provocare attacchi di crampi - nella zona del collo / della carotide: pericolo di provocare un arresto cardiaco - nella zona della faringe e della laringe: pericolo di crampi muscolari che possono cagionare un’asfissia - nelle vicinanze della gabbia toracica: rischio accresciuto di fibrillazione ventricolare che può...
All manuals and user guides at all-guides.com 3. Descrizione dell‘apparecchio Denominazione dei componenti 1. Unità di comando 2. Display LCD 3. Pulsante del programma e di blocco 4. Pulsante On / Off / Pausa 5. Pulsante di selezione Incrementare l’intensità 6.
Seite 32
All manuals and user guides at all-guides.com - Inserire le batterie nel vano rispettando i contrassegni. Prestare attenzione alla posizione corretta dei poli delle batterie. Avvertenze: - In questo apparecchio non possono essere utilizzati accumulatori. - Quando non si utilizza l’apparecchio si consiglia di custodirlo separato dalla cintura. Rimuovere le batterie quando l’apparecchio non viene usato per un lungo periodo.
All manuals and user guides at all-guides.com Spegnimento automatico Se l’apparecchio non viene usato dopo averlo acceso, questi si spegne automaticamente dopo circa 5 minuti. 5. Modalità d’uso Informazioni generali sull’allenamento con la cintura per addominali Nella prima settimana non indossare la cintura per addominali più di una volta al giorno per abituare gradualmente i muscoli all’apparecchio.
Seite 34
All manuals and user guides at all-guides.com Programma Tempo di esercizio Ripetizioni Frequenza di allena- [min] mento [Hz] 45 / 60 60 / 80 continuo Impostazione del livello di intensità Avvertenza: l’intensità può essere impostata solo quando gli elettrodi sono a contatto con la pelle. Prima di iniziare ogni allenamento è...
Utilizzare una leggera lisciva di sapone o un detersivo liquido. Non utilizzare candeggianti. - La cintura non è lavabile in lavatrice. 7. Specifiche tecniche: Modello: EM 30 Alimentazione elettrica: 3 x 1,5 V AAA (tipo LR 03) Dimensione degli elettrodi:...
All manuals and user guides at all-guides.com oluşturulan uyarılma, aktif bir karın kaslarını çalıştırma işlemindeki kadar özel değil, daha genel bir uyarmadır ve bu nedenle karın kas kuşağı tam olarak gerçek ve aktif bir antrenmanın yerini tutmaz ve böyle bir antrenmanı tamamen gereksiz kılmaz. Elektrikli kas stimülasyonu uzun yıllardir sporda ve sağlıklı...
Seite 37
All manuals and user guides at all-guides.com Alette hasar – Alette aşınma, eskime veya hasar olup olmadığını sık sık kontrol ediniz. Böylesi belirtilerin olması halinde veya alet amacına uygun kullanılmamışsa, aleti tekrar kullanılmadan önce, üreticiye veya yetkili satıcıya götürüp göstermeniz gerekir. –...
Seite 38
All manuals and user guides at all-guides.com Kendiliğinden yapışan elektrot bağlantı kapakları yoksa veya çözülüyorsa, ekteki elektrot kapaklarını kesinlikle yapıştırmanızı tavsiye ediyoruz. Kuşağı kesinlikle metal elektrotlar açıkta ve görünür şekildeyken kullanmayınız. Kuşağın elektrot kapakları olmadan kullanılması, yaralanmalara neden olabilir. Gösterge sembollerinin tanım ve tarifi A Pil durum göstergesi: Pil bittiği zaman yanıp söner B Etki seviyesi: Ayarlanmış...
Seite 39
All manuals and user guides at all-guides.com – Kemeri belinize öyle yerleştiriniz ki, elektrotlar karnınızın üzerine otursun. Ardından cırt bantlı bağlantıyı kapatınız. Kemer esnek bir malzemeden yapılmıştır ve farklı bel ebatları için kullanılabilir. Kemerin, elektrotlar ve cildiniz arasında iyi bir temas olacak, fakat sizi sıkmayacak şekilde belinize oturmasına dikkat ediniz.
All manuals and user guides at all-guides.com Cihazın devreye sokulması Açık / Kapalı tuşuna basınız. Kısa bir sinyal sesi duyulur ve LCD göstergesi yanar. Alet ilk kez çalıştırıldığında, otomatik olarak A programı aktifleştirilir. Program seçilmesi Karın kas kuşağı, birbirine uyum sağlayan ve birbirini tamamlayan beş programa sahiptir ve siz bu programları...
Bu işlem için fazla tesirli olmayan sabunlu su veya sıvı deterjan kullanabilirsiniz. Ağartma maddesi kullanmayınız. – Kemer çamaşır makinesinde yıkanmaya uygun değildir. 7. Teknik özellikler: Model: EM 30 Elektrik akımı beslemesi: 3 x 1,5 V AAA (Tip LR 03) Elektrot ebatları: Yakl. 10 x 10 cm Parametre (500 Ohm yük):...
служит порукой высокого качества и многократно проверенной надежности изделий в области тепловой терапии, аппаратов мягкого воздействия, аппаратов для измерения артериального давления и диагностики, для взвешивания, массажа и аэротерапии. С дружеским приветом Ваша фирма «Бойрер» (Beurer) 1. Ознакомление Принцип работы пояса для стимуляции мышц живота...
All manuals and user guides at all-guides.com Примечание: В редких случаях может возникать раздражение кожи в области электродов. Использование не по назначению – Прибор запрещается применять: - в области головы: здесь он может вызывать приступы судорог - в области шеи / сонных артерий: здесь он может вызывать остановку сердца - в...
Seite 44
All manuals and user guides at all-guides.com 3. Описание прибора Наименование деталей 1. Блок управления 2. ЖК -индикатор 3. Кнопка программирования и блокировки 4. Кнопка Вкл / Выкл / Пауза 5. Кнопка увеличения интенсивности 6. Кнопка уменьшения интенсивности 7. Крышка отсека для батареек 8.
Seite 45
All manuals and user guides at all-guides.com – Вытащите прибор через верх из крепления. – Снимите крышку отсека для батареек, нажав на нее и сместив в направлении, указываемом стрелкой. – Вложите батарейки согласно меткам в отсек. Следите за правильностью полярности батареек. Указания: –...
All manuals and user guides at all-guides.com Автоматическое выключение Если прибор после включения не используется, то через 5 минут он автоматически выключается. 5. Применение Общая информация о тренировках с использованием пояса для стимуляции мышц живота В первую неделю не рекомендуется пользоваться поясом чаще раза в день, чтобы дать мышцам медленно...
Seite 47
All manuals and user guides at all-guides.com Программа Длительность [мин] Число повторений Тренировочная частота [Гц] 45 / 60 60 / 80 непрерывно Настройка уровня интенсивности Примечание: Интенсивность может быть настроена только в том случае, если электроды имеют контакт с кожей. Перед...
Используйте для этого мягкий мыльный раствор или жидкое моющее средство. Не используйте отбеливатели. – Запрещается стирать пояс в стиральной машине. 7. Технические данные: Модель: EM 30 Электропитание: 3 x 1,5 В AAA (тип LR 03) Размеры электродов: прибл. 10 x 10 см...
„Ciśnienie krwi”, „Temperatura ciała”, „Waga”, „Masaż” i „Powietrze”. Prosimy o dokładne przeczytanie instrukcji obsługi oraz przestrzeganie wskazówek. Z poważaniem Zespół firmy Beurer 1. Zapoznanie Sposób pracy mięśni brzucha-/-pasa Pas do stymulacji mięśni brzucha pracuje na bazie elektrycznej stymulacji mięśni (EMS).
All manuals and user guides at all-guides.com Użycie niezgodne z przeznaczeniem – Urządzenia nie należy stosować: - na głowie: może tu dojść do skurczy w obszarze szyi/tętnicy szyjnej może także spowodować zatrzymanie akcji serca – w obszarze gardła i krtani: może tu spowodować skurcze mięśni, mogące doprowadzić do uduszenia –...
Seite 51
All manuals and user guides at all-guides.com 3. Opis urządzenia Nazwy części 1. Sterowanie 2. Wyświetlacz ciekłokrystaliczny 3. Przycisk programu i zatrzymania 4. Przycisk włącz/wyłącz/pauza 5. Przycisk podwyższania intensywności 6. Przycisk zmniejszania intensywności 7. Pokrywa kieszeni baterii 8. Mocowanie 9. Elektrody powierzchniowe 10.
All manuals and user guides at all-guides.com Wskazówki: – Nie używać w urządzeniu akumulatorków. – Jeśli urządzenie nie jest używane, zaleca się oddzielne przechowywanie pasa i urządzenia. Jeśli urządzenie nie będzie przez dłuższy czas używane, zaleca się wyciągnięcie baterii. – Zużytych baterii nie wyrzucać do zwykłych śmieci. Istnieje ustawowy obowiązek utylizacji baterii.
All manuals and user guides at all-guides.com 5. Zastosowanie Informacje ogólne dotyczące stymulacji przy pomocy pasa W pierwszym tygodniu używania pasa nie należy stosować go częściej niż raz dziennie, aby przyzwyczaić mięśnie do urządzenia. Po tym czasie można trenować częściej. Wskazówka: Do regeneracji mięśnie potrzebują...
Seite 54
All manuals and user guides at all-guides.com Ustawianie poziomu intensywności Wskazówka: Intensywność można nastawić tylko wtedy, gdy elektrody mają kontakt ze skórą. Poziom intensywności należy ustawić na początku każdego treningu. Nacisnąć przycisk , aby zwiększyć intensywność i , aby zmniejszyć. W zależności od intensywności odczuwa się...
All manuals and user guides at all-guides.com 7. Dane techniczne: Model: EM 30 Zasilanie prądem: 3 x 1,5 V AAA (typ LR 03) Wielkość elektrody: ok. 10 x 10 cm Parametry (obciążenie 500 Ohm): – Napięcie wyjściowe: maks. 70V p-p –...
Seite 56
