Connecting the plug-in power supply (optional)

The 12 V plug is optionally available.
Prior to charging the batteries using the plug-in power sup-
ply, the solar cell must be disconnected from the control unit
(terminals S1 and S2). Attach the yellow terminal to S1+ and
the blue terminal to S2-. The red charging voltage indicator
lamp lights up during the charging process. The battery is
fully charged after approx. 2 hours.
Roller shutter operation / venetian blind operation
You can switch between roller shutter operation and venetian blind operation.
Roller shutter operation (factory setting)
By pressing a travel button, the roller shutter moves to the set limit position in
maintained operation mode.
Venetian blind operation
For venetian blind operation, you can operate the receiver in touch mode. If
you press the travel button for longer than 1 second, the venetian blind runs in
maintained operation mode.
Yellow (S1+)
Blue (S2-)

Explanation of functions
