Montageanleitung / Assembly instruction / Notice de montage
ECO SR III
ECO SR III
ECO SR III
Assembly for active leaves DIN left is described below. For active leaves DIN right, please proceed accordingly.
Attach drilling template and choose corresponding drill holes depending on mounting situation (direct mounting,
mounting with standard profile or mounting with adaptor plate). Drill holes.
Drill the hole pattern according to the drawing.
1a-c
Insert the end caps into the active leaf slide rail (G) and into the passive leaf slide rail (S).
2
Insert the middle pieces into the active leaf slide rail (G) and into the passive leaf slide rail (S). The lugs on the
3+4
middle pieces have to point forwards and downwards!
Direct mounting
5a
Screw on door closer mounting plates.
Mounting with adaptor plate (ADP 30)
5b
Screw on adaptor plate (optional), shorten if necessary
Mounting with standard profile (ADP 20)
5c
Screw on standard profiles (optional), shorten if necessary
Direct mounting
6a
Mount active leaf slide rail and passive leaf slide rail directly.
Mounting with adaptor plate (ADP 30)
6b
Mount active leaf slide rail and passive leaf slide rail onto adaptor plate.
Mounting with standard profile (ADP 20)
6c
Mount active leaf slide rail and passive leaf slide rail onto standard profile.
Fit door closer.
7
Close closing speed valve
8
Open speed valves. Close doors.
Adjust the doorcloser as stated in the separate mounting instruction.
9
Determine dimension x in line with drawing
10
x + 202 mm and trim
Push coupling sleeves as depicted onto the connecting rod
11
rod between the rod ends
the screws of the coupling sleeves have to point downwards.
Determine dimension y acc. to drawing
12
the cover profile
2
Attach cover profile to mounting profile
13
Functionality test SR
Open both doors approx. 60°, active leaf has to remain open. Passive leaf closes. Active leaf is only allowed to
close if the passive leaf reaches a closing angle of approx. 30°.
Attach nylon clips
14
(DIN links / DIN rechts spiegelbildlich)
(DIN left / DIN right mirror image)
(DIN gauche / DIN droite inverser l'illustration)
. Guide the lever arm in the direction of the slide rail
1
.
2
. Push the coupling sleeves over the rod ends and tighten grub screws
3
1
.
, adjust it and fix it
1
. Clip on U-Cover
and pinion cover
1
2
.Screw on door closer mounting plates
1
.Screw on door closer mounting plates
1
. Cut connecting rod to length in line with said dimension
1
. Turn the connecting rod by 90°
1
. Cut to length the U-cover profile to dimension y - 6mm and deburr
.
2
.
3
.
2
.
2
and connect to the slide rail .
2
.Push connecting
2
. Attention:
4
3
10/16
