Schnellwechselplatte nutzen 1. Lösen Sie den Plattform-Verriegelungsknopf. 2. Legen Sie die Wechselplatte ein, wie auf den Bildern gezeigt. 3. Kippen Sie die Platte, um erst eine Seite einzulegen, dann die andere. 4. Drehen Sie die Platte mit dem Plattform-Verriegelungsknopf fest. Anti-Rutsch- Schraube Anti-Rutsch-...
Produktübersicht Stativ Basis-Plattform Mittesläulen-Horizontal-Feststellschraube Mittelsäulen-Panorama-Feststellschraube Mittelsäule Haken zum Aufhängen von Sandsack oder Rucksack Schnellverschlüsse Feststellknopf für die Mittelsäule Silikongriff Abnehmbare Füße / integrierte Spikes Hinweis: Plattform an der mittleren Mittelsäule mit der Feststellschraube sichern. DEUTSCH...
Umbau zum Einbeinstativ 1. Schrauben Sie das Bein mit Silikongriff ab. 2. Schrauben Sie den Kugelkopf und die Basisplatte ab. 3. Schrauben Sie die Basisplatte und den Kugelkopf auf das abgeschraubte Bein. Einstellung des Winkels: Drücken Sie die Winkel-Taste an der Schulter, um den Winkel des Beins einzustellen.
Einstellung der Mittelsäule 1. Schrauben Sie den Haken an der Mittelsäule los und nehmen Sie ihn heraus. 2. Lösen Sie die Mittesläulen-Horizontal-Feststellschraube, bis Sie die Mittel- säule herausziehen können. 3. Lösen Sie die Mittelsäulen-Panorama-Feststellschraube und kippen Sie die Mittelsäule an die gewünschte Position. 4.
Technische Daten Stativ C5i Makro Pro inkl. Kugelkopf Material Aluminium Sektionen Stativbeindurchmesser Max. Ø 25 mm Packmaß 44 cm Minimale Höhe 13,5 cm Maximale Arbeitshöhe 132 cm Maximale Höhe 159 cm Gewicht 1,66 kg Maximale Traglast 8 kg Einbeinstativ inkl. Kugelkopf Minimale Höhe...
Using the Quick Release Plate 1. Loosen the platform locking knob. 2. Insert the interchangeable plate as shown in the pictures. 3. Tilt the plate to insert one side, then the other. 4. Tighten the plate with the platform locking knob. Anti-slip screw Anti-slip...
Product Overview Tripod Base platform Centre-column horizontal locking screw Centre-column panoramic locking screw Centre column Hook for hanging sandbag or rucksack Quick release fasteners Locking knob for the centre column Silicone handle Removable feet / integrated spikes Note: Secure the platform on the middle centre column with the...
Conversion to Monopod 1. Unscrew the leg with silicone grip. 2. Unscrew the ball head and base plate. 3. Screw the base plate and ball head onto the unscrewed leg. Adjusting the angle: Press the angle button on the shoulder to adjust the angle of the leg. Foldable by 180°.
Adjusting the Centre Column 1. Unscrew and remove the hook on the centre column. 2. Loosen the centre column horizontal locking screw until you can pull out the centre column. 3. Loosen the centre column panorama locking screw and tilt the centre column to the desired position.
Technical Data Tripod C5i Makro Pro incl. ball head Material Aluminium Sections Tripod leg diameter Max. Ø 25 mm Packing size 44 cm Minimum height 13.5 cm Maximum working height 132 cm Maximum height 159 cm Weight 1.66 kg Maximum load 8 kg Monopod incl.
Seite 16
Rollei GmbH & Co. KG In de Tarpen 42 D-22848 Norderstedt Service Hotline: +49 40 270750277 /rollei.foto.de @rollei_de Item No.: 22959 www.rollei.com...
