Single Digit (1-9)
Memory LED Display
Tension Index Buttons - Changes
tension setting in +/- 1.0 or +/- 0.1 Lb or
Kg increments. Holding the button down
will scroll the tension setting values up
or down. Tension settings entered with
the tension index buttons are placed into
temporary memory setting "0".
Clear Button - Clears display to enter
a new tension or to reset String Length
Meter measurement.
Test Button & Racquet Strung -
Press once for approximate number of
racquets strung. Press again to return.
Press and hold for 5 seconds and the
machine does an internal diagnostic
check, such as the one performed at
start-up.
Lbs/Kgs Button - Changes tension
display from Lbs to Kgs. Each press
of the button toggles back and forth
between Lbs and Kgs.
Pre-Stretch Function - Pulls string 10%
or 20% over the tension setting (up to 90
lbs / 40.8 kgs), releases the string, and
repulls to the tension setting. Each press
of the button toggles between 10%, 20%
or no pre-stretch.
6
Three Digit (XX.X) Ten-
sion Setting Display
or String Length LED
Display
Memory Button - Indexes from 9 preset
tension settings that can be stored in
memory. Settings are retained even if
machine is turned off. Each press of
the button indexes to the next memory
setting. Memory settings 1-9 must be
entered using the keypad followed by
pressing the "ENT" button.
Enter Button - Saves displayed tension
for Memory setting - when tension is en-
tered using the keypad display fl ashes
until this button is pressed to save the
setting. Also Clears display for String
Length Meter measurements.
Knot Function - Increases pulling ten-
sion by 10% over the setting value (max
90 lbs / 40.8 kgs) for one pull. During the
pull the LED stays lit to indicate the Knot
function is enabled.
Speed Button - Changes pulling speed
of winder from Fast (default) to Medium
to Slow. Slow speed is recommended
for low stretch strings, such as Kevlar.
Each press of the button toggles be-
tween Fast, Medium and Slow speeds.
String Length Meter Button - feature is
currently not available.
Adjustment
Knob
Uhrzeigersinn angepasst werden, um die Lücke zwischen der Zange zu
öffnen. Die Zangen sollten regelmäßig gereinigt werden, um von Schmutz,
Öl und jedem Saiten-Rückstand frei zu sein, um richtig zu greifen.
Cleaning Stones sind bestens geeignet, um Reste auf der
diamantbeschichteten Oberfläche zu entfernen.
Die Zangen werden geringe Anpassungen
brauchen, je nachdem welche Saiten-
stärke Sie verwenden. Wenn die Saite
durch die Zange gleitet, ziehen Sie
die Zange zusammen, indem Sie die
Klemmbacken mit der Hand zusammen
drücken, während Sie die
Justierschraube im Uhrzeigersinn
drehen. Wenn die Zange Eindrücke
hinterlässt oder die Saite beschädigt
wird, kann es übermäßig dicht sein
und sollte durch das Drehen der
Justierschraube entgegen dem
Quick Action
Quick Action
15
