5.3 Preparing the pump (Fig. 3)
•
Open the ventilation screw (4) so that air can
escape when the pump housing is being
filled.
•
Use the supplied wrench (9) to unscrew the
coarse filter cap (3) and then remove the
coarse filter (13). Now you can fill the pump
housing with water via the coarse filter cap
(3). Filling the intake line will accelerate the
priming process.
•
Assemble in reverse order.

5.4 Electrical connection

•
The electrical connection needs a shook-
proof socket for 220-240 V~ 50 Hz. Minimum
10-amp fuse required.
•
The motor is protected from overload or blo-
ckage by a built-in temperature monitor. The
temperature monitor will switch off the pump
automatically if overheating occurs, and it will
switch on the equipment again automatically
when it has cooled down again.
5.5 Connection of the additional antenna
The pump comes with an integrated antenna. In
most cases the wireless signal of the integrated
antenna is strong enough for automatic operati-
on. To boost the wireless signal you can use the
additional antenna which is included in delivery.
This might be required, for example, if the pump
is installed in a basement behind thick walls or
in a shed lined with metal sheeting. The antenna
is best positioned outside the space with the
shielding eff ect. Insert the end of the supplied
additional antenna (10) into the pump's antenna
connection (11) and screw the union nut in place
until it is hand-tight (Fig. 4). The pump will now
use the external additional antenna.
5.6 Controlling the pump using the app
You can use the app to call up numerous setting
options for your pump and to view its perfor-
mance data. Manual remote control is possible on
the basis of a defi ned work period or in SMART
mode. The app presents you with error messages
and warnings during operation.
Anl_GE_AW_1144_SMART_SPK13.indb 20 Anl_GE_AW_1144_SMART_SPK13.indb 20
GB

5.6.1 Downloading the app

First download the Einhell app for your pump onto
your smart-phone. The Einhell app is available via
the following link and QR code:
iOS: http://qr.einhell.com/12e103ce
Android: http://qr.einhell.com/176c0443
5.6.2 Registering the pump
The pump comes with an IoT function (IoT = In-
ternet of Things). It uses an integrated SIM chip to
connect to the available mobile network, making
it independent of Bluetooth or WLAN. In the fi rst
5 years you will not be charged anything for using
the pump in the mobile network; these costs are
covered by the purchase price. Information about
the remaining period of use and the possibility of
an extension can be consulted in the app. In the
factory default state the function is deactivated;
the pump will try to connect to the network, indi-
cated by the network LED blinking blue (Fig. 5/
Item C). To activate your pump, follow the instruc-
tions in the app.
After successful registration and connection with
the network, the network LED will light up blue
(Fig. 5/Item C) and the app's diverse setting op-
tions and functions will be available for you to use.
Make sure that both the pump and your smart-
phone have a secure internet connection once
you have made any settings in the app. For the
pump to be operated automatically within a pro-
grammed work period, the only requirement is for
the pump to be connected with the internet.
