Electric Drives Linear Motion and and Controls Hydraulics Assembly Technologies Pneumatics Service Rexroth PSI 6xxx.224 1070087028 Edition 02 Mittelfrequenz-Umrichter Medium-Frequency Inverter Typspezifi sche Anleitung | Type-Specifi c Instructions...
Seite 2
Eigenschaften. Die Angaben entbinden den Verwender nicht von eigenen Beurteilungen und Prüfungen. Unsere Produkte unterliegen einem natürlichen Verschleiß- und Alterungsprozess. Alle Rechte bei Bosch Rexroth AG, auch für den Fall von Schutzrechtsanmeldungen. Jede Verfügungsbefugnis, wie Kopier- und Weitergaberecht, bei uns.
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 5/59 Zu dieser Dokumentation Zu dieser Dokumentation Gültigkeit der Dokumentation Diese Dokumentation gilt als Ergänzung für den Mittelfrequenz-Umrichter der Baureihe PSI 6000. Der Inhalt bezieht sich auf den Anschluss (Netzversorgung) die Funktionalität des Mittelfrequenz-Umrichter Steuerungsteils.
6/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Zu dieser Dokumentation Darstellung von Informationen Damit Sie mit dieser Dokumentation schnell und sicher mit Ihrem Produkt arbeiten können, werden einheitliche Sicherheitshinweise, Symbole, Begriffe und Abkürzungen verwendet. Zum besseren Verständnis sind diese in den folgenden Abschnitten erklärt.
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 7/59 Sicherheitshinweise Sicherheitshinweise Dieses Kapitel enthält wichtige Informationen zum sicheren Umgang mit dem beschriebenen Produkt. Die Sicherheitshinweise sehen Sie bitte unter Tab. 1: Erforderliche und ergänzende Dokumentationen Rexroth PSI6xxx Mittelfrequenz-Umrichter Betriebsanleitung nach. Allgemeine Hinweise vor Sachschäden und Produktschäden...
12/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Ein/Ausgangsfeld Ein/Ausgangsfeld Diskretes 24V Ein-/Ausgangsfeld Tabelle 1: Diskrete Eingänge Bits Eingänge: E 00 Verknüpft mit seriellem Ausgang Bit_016 E 01 Verknüpft mit seriellem Ausgang Bit_017 E 02 Verknüpft mit seriellem Ausgang Bit_018 E 03 Verknüpft mit seriellem Ausgang Bit_019...
Seite 13
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 13/59 Ein/Ausgangsfeld Tabelle 2: Diskrete Ausgänge Bits Ausgänge: A 00 Verknüpft mit seriellem Eingang Bit_016 Elektrodenfräseinrichtung Ein A 01 Verknüpft mit seriellem Eingang Bit_017 A 02 Verknüpft mit seriellem Eingang Bit_018 A 03 Verknüpft mit seriellem Eingang Bit_019...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 21/59 Ein/Ausgangsfeld Tabelle 17: Serielle Ausgänge Bits Ausgänge (Wort 4): Bit_064 Status Bit 0 Bit_065 Status Bit 1 Bit_066 Status Bit 2 Bit_067 Status Bit 3 Bit_068 Status Bit 4 Bit_069 Status Bit 5...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 23/59 Merkmale Punktnummern kleiner 256 werden von der Steuerung als Programmnummer interpretiert. 7.1.2 Elektrodenpflege Die Elektrodenstatusausgänge und die Quittungseingänge (Fräsen, Elektrodenwechsel) beziehen sich auf die Elektrode, die dem aktuell angewählten Programm zugeordnet ist. Beim Quittieren von Fräsen oder Elektrodenwechsel für Elektrode 0 gilt die Quittung für alle Elektroden.
24/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Merkmale 7.1.5 Prop.-Ventil Anwahl Der hier ausgegebene absolute Wert entspricht dem Wert, der in der Steuerung abgespeichert wurde. Die Dimensionierung dieses Wertes wird extern festgelegt. Elektrodenfräseinrichtung Ein 7.1.6 Der serielle Eingang Bit_16 „Elektrodenfräseinrichtung Ein“ wird transparent an den diskreten Ausgang A_00 „Elektrodenfräseinrichtung Ein“...
26/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Merkmale 7.2.3 Leistungsvorwarnung (ab Firmware-Version –108): Nach jedem Schweißablauf wird eine Phasenanschnittsüberwachung durchgeführt. Der mittlere Phasenanschnitt wird mit den Elektrodenparametern obere Leistungsbegrenzung obere Leistungsvorwarnung untere Leistungsvorwarnung verglichen. Wird eine der Grenzen überschritten, wird eine Warnung ausgegeben.
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 27/59 Merkmale 7.2.5 Zyklische Speichertests (ab Firmware-Version –110): Die Steuerung führt im Hintergrund einen Test des Parameterspeichers durch. Wird ein Fehler erkannt, wird eine Warnmeldung „RAM Checksummenfehler“ mit einem Zusatzcode ausgegeben, der sich wie folgt zusammensetzt:...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 29/59 Ablaufdiagramme Ablaufdiagramme Programm /Punktanwahl Neue Punktanwahl Daten zur Punktanwahl gültig Analoger Druck Ausg / Prop. Ventil Auswahl Mit Schweißstrom Programmstart Fortschaltkontakt FK (Start/Dauer vor Ende NHZ programmierbar) 1. Vorhaltezeit Vorhaltezeit 1. Stromzeit 1.
Seite 30
30/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Ablaufdiagramme Programm /Punktanwahl Neue Punktanwahl Daten zur Punktanwahl gültig Mit Schweißstrom Analoger Druck Ausg. / Prop. Ventil Auswahl Programmstart Fortschaltkontakt FK (Start/Dauer vor Ende NHZ programmierbar) 1. Vorhaltezeit Vorhaltezeit 1. Stromzeit 1. Pausenzeit 2.
Seite 31
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 31/59 Contents Contents To this Documentation................33 Validity of the documentation ............33 Required and supplementary documentation........33 Display of information............... 33 1.3.1 Safety instructions ............33 ...
Seite 32
32/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Contents...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 33/59 To this Documentation To this Documentation Validity of the documentation This documentation applies to Rexroth Medium-Frequency Inverter PSI 6000. The content belong to Connection (power supply) Functionality of the Rexroth Medium-Frequency Inverter.
34/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 To this Documentation Meaning of the Symbols Tab. 2: Symbol Meaning If this information is disregarded, the product cannot be used and or operated to the optimum extent. Single, independent step ...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 35/59 Safety instructions Safety instructions The Safety instructions please look in Tab. 1: Required and supplementary documentation Rexroth PSI6xxx Medium-Frequency Inverter Instruction Manual. General notes for property damages and product damages General notes for property damages and product damages please look in Tab. 1: Required and supplementary documentation Rexroth PSI6xxx Medium- Frequency Inverter Instruction Manual.
Seite 37
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 37/59 Connection diagram RxD/TxD -P Cntr-P DGnd RxD/TxD -N Linked to serial O bit16 Linked to serial O bit17 Linked to serial O bit18 E 02 Linked to serial O bit19 E 03...
Seite 38
38/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Connection diagram Fig. 3: Connection diagram examples...
40/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Input/Output array Input/Output array Discrete 24VDC input/output field Discrete inputs Tab. 4: Bits Inputs: E 00 Linked to serial O bit16 E 01 Linked to serial O bit17 E 02 Linked to serial O bit18...
Seite 41
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 41/59 Input/Output array Discrete outputs Tab. 5: Bits Outputs A 00 Linked to serial I bit16 Electrode tipp dressing device ON A 01 Linked to serial I bit17 A 02 Linked to serial I bit18...
42/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Input/Output array Serial input/output field Serial input/output field with 160 serial inputs ( word 0 to word 9, Bit_000 to Bit 159 ) and 80 serial outputs ( word 0 to word 4, Bit_000 to Bit_079 ): Serial input field Tab.
Seite 43
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 43/59 Input/Output array Bits Inputs (word 1) Bit_031 Linked to discrete output A15 Serial input field Tab. 8: Bits Inputs (word 2) Bit_032 Not used Bit_033 Not used Bit_034 Not used Bit_035 Not used...
Seite 44
44/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Input/Output array Bits Inputs (word 3) Bit_063 Spot selection Bit 15 Tab. 10: Serial input field Bits Inputs (word 4) Bit_064 Spot selection Bit 16 Bit_065 Spot selection Bit 17 Bit_066 Spot selection Bit 18...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 49/59 Input/Output array Tab. 20: Serial output field Bits Outputs (word 4): Bit_064 Status Bit 0 Bit_065 Status Bit 1 Bit_066 Status Bit 2 Bit_067 Status Bit 3 Bit_068 Status Bit 4 Bit_069...
50/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Features Features Sequence standard 1000 Hz (sequence parameters in milliseconds) I/O Module : PS5 Comnet-M-DP module (Details refer to Tab1. Required and supplementary documentation, Rexroth PSI6xxx Medium-Frequency Inverter Instruction Manual). Special features The welding controller features the following specifics: ...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 51/59 Features -or reset the output „Timer ready“, then a general error was occurred. If the robot reset the input „Program start“, then the control will reset the output „Weld complete“. In a schedule with fault, the fault has to be corrected and acknowledged.
52/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Features Via the output „tipp dresser end of life“ a group signal for all tipp dresser will be send, if a program is selected which is assigned to electrode 0 (since firmware version 110).
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 53/59 Features Special features with operation mode „US“: With global activated US measurement no diode temperature monitoring will be done. (Display: 0°). If in a welding sequence the US monitoring activated, then will be done no current monitoring , also if it is activated.
54/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Features 7.2.2 Monitoring of the tipp dressing result (since firmware version 108): The welding control monitors with the following routine the tipp dress result with heat value and the current as follows: The user defines a welding program for tipp dress monitoring.
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 55/59 Features For applications involving the UI controller, the phase value of the sample curve is set in the PstWLD while the UI controller is active if PHA mode has been selected as the control mode for PstWLD.
56/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Status codes Status codes Tab. 23: Status codes Code (decimal) Meaning Stop / No 24V Weld without command Memory deleted == RAM checksum error Data restore to timer in process No schedule programmed == invalid parameter...
1070087028 | PSI 6xxx.224 Bosch Rexroth AG 57/59 Timer diagrams Timer diagrams Program/spot selection New spot selection Data for spot selection valid Pressure output With welding current Program start Weld complete contact WC (Start/Duration before end of hold can be programmed)
Seite 58
58/59 Bosch Rexroth AG 1070087028 | PSI 6xxx.224 Timer diagrams Program/spot selection New spot selection Data for spot selection valid With welding current Pressure output Program start Weld complete contact WC (Start/Duration before end of hold can be programmed) Pre-squeeze time...
Seite 59
Bosch Rexroth AG Electric Drives and Controls P.O. Box 13 57 97803 Lohr, Germany Bgm.-Dr.-Nebel-Str. 2 97816 Lohr, Germany Tel. +49 9352 18 0 +49 9352 18 8400 www.boschrexroth.com/electrics 1070087028 DOK-PS6000-PSI6XXX.224-IT02-D0-P...
