02.2005
Installation
Cutouts
Mounting surface
for M5 screws
250 mm
22.5 mm
135 mm
180 mm
220 mm
5.5 / 7.5 / 11 kW
15 - 37 kW
Side view
Front view
Fig. 5-3
Dimension drawings for housings 135 mm and 180 mm wide
Siemens AG
6SE7087-6KP60
5-3
SIMOVERT MASTERDRIVES
Operating Instructions
