1. Description
(Figure 1/2)
1 Pin guide
The pin guide guides the blade and prevents it
from twisting during the sawing operation.
Whenever the blade is changed you have to re-
adjust the pins.
2 Fixing screw
The fixing screw is used to fix the upper blade
guide in place.
3 Fixing handle for table adjustment
After releasing the fixing handle you can adjust
the angle of the table as required.
4 Dial scale for table adjustment
Use the dial scale underneath the table as a
reference for quickly setting the approximate
angle.
N.B.: To set the exact angle required, carry out a
trial cut and make further adjustments as
necessary.
5 Knurled screw for setting the blade tension
Use this screw to set the necessary blade
tension.
6 Blade adjusting screw
Use this adjusting screw to ensure the blade
runs centrally on the blade pulleys.
7 Connection socket for saw dust extractor
Use this socket to connect a saw extraction
system or an industrial vacuum cleaner to
remove the saw dust and chips.
Internal/external socket diameter: 40/45 mm
8 Switch with undervoltage release
Your bandsaw has a switch with undervoltage
release. After a power failure you must
reactivate the switch.
Press (I) to switch on.
Press (O) to switch off.
9 Adjustable cross fence
10 Parallel fence
11 Fixing screw for the parallel fence
12 Spring
13 Machine table

2. Items supplied

Bandsaw
Machine table
Parallel fence
Mitre fence
Hexagon socket-head wrench
Standard blade
Operating instructions
16.10.2001 10:31 Uhr Seite 11
3. Proper use
Assemble the bandsaw as described in Section 7
„Assembly". Use only those parts supplied. The
bandsaw is to be used only to saw squared timber or
wood-type workpieces. To cut round materials you
have to use suitable holding devices.
The machine is to be used only for its prescribed
purpose.
Any use other than that mentioned is considered to
be a case of misuse. The user/operator and not the
manufacturer shall be liable for any damage or injury
resulting such cases of misuse. The machine is to be
operated only with suitable saw blades. It is
prohibited to use any type of cutting-off wheel.
To use the machine properly you must also observe
the safety regulations, the assembly instructions and
the operating instructions to be found in this manual.
All persons who use and service the machine have
to be acquainted with this manual and must be
informed about its potential hazards.
It is also imperative to observe the accident
prevention regulations in force in your area.
The same applies for the general rules of
occupational health and safety.
The manufacturer shall not be liable for any changes
made to the machine nor for any damage resulting
from such changes.
Even when the machine is used as prescribed it is
still impossible to eliminate certain residual risk
factors. The following hazards may arise in
connection with the machine's construction and
design:
Damage to hearing if essential ear-muffs are not
worn.
Harmful emissions of wood dust when the
machine is used in closed rooms.
Do not reach into the uncovered cutting area of
the blade! Risk of injury to hands!
Risk of injury when changing the blade! Beware
of cutting your fingers etc.
Risk of injury from catapulted workpieces or
parts of workpieces.
Beware of crushing your fingers.
Risk of injury from kick-back.
Beware of the workpiece slipping on a poor
support surface.
Beware of touching the blade.
Beware of catapulted pieces from branches and
workpieces.
