TZIDC, TZIDC-110, TZIDC-120 DIGITALER STELLUNGSREGLER | 42/18-84-DE REV. F

CSA certification record

Certificate
Certificate
Class 2258 04

Electrical data

Model TZIDC, P/N V18345-x0x2x2xx0x Intelligent Positioner
For use in
Input rated
Output pressure
Intrinsically safe with entity parameters of:
Terminals 11 / 12
Terminals 81 / 82
Terminals 83 / 84
Terminals 31 / 32
Terminals 41 / 42 and 51 / 52
Terminals Limit 2 41 / 42
and Limit 1 51 / 52
When installed per installation Drawing No 901064:
Temperature Code
Max. Ambient temperature
1649904 (LR 20312)
PROCESS CONTROL EQUIPMENT –
Intrinsically Safe, Entity – For Hazardous
Locations
Class I, Div 1, Groups A, B, C and D;
Class II, Div 1, Groups E, F, and G,
Class III, Div 1, Enclosure Type 4X
30 V DC; max.4 to 20 mA
Max. 90 psi
V max = 30 V C
I max = 104 mA
V max = 30 V C
I max = 110 mA
V max = 30 V C
I max = 96 mA
V max = 30 V C
I max = 110 mA
V max = 30 V C
I max = 96 mA
V max = 15.5 V C
I max = 52 mA L
Note
• The 'x' in P/N denotes minor mechanical variations or
optional features.
• Local communication interface LCI shall not be used in
hazardous location.
• Each pair of conductors of each intrinsic safety circuit shall
be shielded.
• See FM installation drawing No. 901064 for Details.
FM approvals
TZIDC Positioner, Model V18345-a0b2c2de0f
IS/I,II,III/1/ABCDEFG/T4 Ta = 85 °C – 901064/7/4; Entity;
NI/I/2/ABCD/T4 Ta = 85 °C;
S/II,III/2/FG/T4 Ta =85 °C; Type 4X
Max entity Parameters: Per Control Drawings
a Case/mounting – 1, 2, 3, 4 or 9
b Input/communication port – 1 or 2
c Output/safe protection – 1, 2, 4 or 5
d Option modules for analog or digital position feedback – 0, 1,
= 6.6 nF
i
3 or 5
L = 0 µH
i
e Mechanical kit (proximity switches) for digital position
= 3.7 nF
feedback (option) – 0, 1 or 3
i
L = 0 µH
f Design (varnish/coding) – 1 or 2
i
= 3.7 nF
i
See FM installation drawing No. 901064 for details.
L = 0 µH
i
= 6.6 nF
i
L = 0 µH
i
= 3.7 nF
i
L = 0 µH
i
= 20 nF
i
= 30 µH
i
T4
85 °C
