Checking the chain
brake
The motor cannot be turned on if the
chain brake has engaged. Do not
employ the chain brake in order to
start the chainsaw or to switch it off.
1. Place the chainsaw onto a solid, fl at
surface. It must not contact any objects.
2. Ensure that the chain brake has been
released, that is, that the chain brake
lever (6) is pulled up against the front
grip (5).
3. Hold the chainsaw fi rmly with both
hands, with the right hand on the rear
handle ( 1) and the left hand on the
front handle (
must close securely over the handles.
4. Turn on the chainsaw.
5. Activate the chain braking lever (6),
with running motor, with the left hand.
6. Once the chain brake is working prop-
erly, release the on/off switch (2) and
the chain brake.
If the chain brake does not
function correctly, you must
not use the chainsaw. A slack
saw chain leads to danger of
injury. Return the chainsaw to
our Service-Center for repair.
Checking the oil automatic
system
Check the oil level and the automatic oil
system before commencement of work.
• Switch on the chainsaw and hold it
above a bright background. The saw
must not touch the ground.
If an oil trace can be seen, the chain-
saw is working trouble-free.
18
5). Thumb and fi nger
If no oil trace can be seen clean the
oil passages or turn the chainsaw
to our Service-Center for repair.
Clean the oil passages of the chain
bar (24), in order to guarantee a
trouble-free, automatic oiling of the
saw chain during operation.
Changing the saw bar
1. Place the battery (
device (see "Inserting/removing the
rechargeable battery").
2. Lay the saw on a fl at surface.
3. Turn the fastening bolt (10) and the
screw for the chain quick-tensioning
system (11) in counter-clockwise
direction in order to loosen the chain
tension and to remove the sprocket
chain wheel cover (12).
4. Remove the saw bar (8) and saw chain
(7). To remove the guide bar (8), raise
it to an angle of approx. 45 degrees.
This will make it easier to take the saw
chain (7) off the sprocket (20).
5. Replace the blade and install the blade
and chain as described under "Install-
ing the sawing chain and blade".
Refer to the start-up section on how
to tension the saw chain.
Sawing techniques
General
Observe the noise protection and
local regulations when cutting
wood. Local requirements may
require a suitability test. Ask the
forestry commission.
16) into the
