Umgebungsbedingungen - Isolationskennwerte
Rated insulation voltage U
i
Rated impulse withstand voltage U
Overvoltage category
Degree of pollution
Elektrische Daten
Operating voltage
No-load supply current I
, maximum
0
Current consumption with magnet ON, average
Current consumption with magnet ON, peak
Rated operating voltage
Required rated short-circuit current
External wire and device fuse rating
Time to readiness, maximum
Switching frequency, maximum
Elektrische Daten - Magnetansteuerung
Designation, Magnet control
Switching thresholds
Current consumption at 24 V
Magnet switch-on time
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Elektrische Daten - Sichere digitale Eingänge
Designation, Safety inputs
Switching thresholds
Current consumption at 24 V
imp
32 VDC
0,8 kV
III
3
24 VDC -15 % / +10 % (stabilisiertes PELV-Netzteil)
100 mA
200 mA
350 mA / 200 ms
24 VDC
100 A
2 A gG
5.000 ms
0,5 Hz
IN
-3 V ... 5 V (Low)
15 V ... 30 V (High)
10 mA
100 %
5 ms
40 ms
C0
C1
C2
C3
X1 und X2
−3 V ... 5 V (Low)
15 V ... 30 V (High)
5 mA
8-31
