Installation
Step 1: Open the fan assembly
Turn the 11 Front Grille counterclockwise until it separates from the
Rear Grille, as shown in figure
13
as indicated by figure , then take out the
②
①
２
Fan Assembly
②
11 12
Front Grille
Fan Blade Assembly
. Remove the front and rear grille
①
Fan Blade Assembly.
12
13
Rear Grille
Step 2: Install the rear grille
Install the Rear Grille onto the motor's sha with "
13
upwards, and then turn the
firmly fix the rear grille to the sha .
13
Step 3: Install the fan blade assembly
Align the center hole of the fan blade assembly with the motor's
sha and install it onto the sha , then install the
Assembly Knob onto the motor's sha . Turn the knob counter-
clockwise to fix the fan blade assembly to the motor's sha .
5
" facing
Rear Grille Knob clockwise to
５
５
Fan Blade
４
４
