Xiaomi Intelligenter Standventilator 2 Pro Benutzerhandbuch Seite 9

Installation
Step 1: Open the fan assembly
Turn the 11 front grille counterclockwise until it separates from
the 13 rear grille. Remove the front and rear grille, then take out the
fan blade assembly.
12
２
11 12
Step 2: Install the rear grille
Install the
upwards, and then install and turn the
clockwise to firmly fix the rear grille to the sha of the motor.
Step 3: Install the fan blade assembly
Align the center hole of the
motor's sha to install it into position, then install the
blade assembly knob onto the motor's sha . Turn the knob
counterclockwise to fix the fan blade assembly to the motor's
sha .
13
7
13 rear grille onto the motor with "
13
12 fan blade assembly with the
12
" facing
6 rear grille knob
6
fan
5
5
