Once the laser beam has been detected, mark the position shown at
•
the edge of the clamp.
Note:
When looking for the laser beam by using a measuring rod, slightly
•
loosen the adjusting knob (17) to move the receiver up or down more
easily. When laser beam has been found securely, tighten the clamp to
ensure the receiver remains stable on the rod.
When marking, take care to align the tool exactly vertical (for horizontal
•
laser beam), or horizontal (for vertical laser beam), as otherwise the
Be sure to refer to the back of the receiver for the measurement of the
•
compensation value (the distance from the top of the receiver to the
center mark), if the top of the receiver is used as a marking position.
-9-
