RFC Remote Control
The RFC can be operated with any Chauvet RF enabled fixture. RF wireless control must be set on the fixture. To enable
RF wireless control in the fixture, locate the RF function in the Menu Map and enable RF.
Binding
To bind the fixture to the remote, navigate to the BIND option in the fixture's menu and follow instructions.
Once the remote has bound to the fixture, it is possible to select a group on the fixture. Assigning the
fixture to a group will be important when using the remote, as the remote can command multiple
groups at once.
Battery Power
The RFC is battery operated. Ensure that the Alkaline battery (A23) is installed prior to operating the remote.
Movement may cause the back lights to turn on and drain the battery while being transported. Turn
off the unit when not in use.
Operation
RFC
<BLACK OUT> Press to turn off all lights until the button is pressed again
<STROBE>
<SPD/SENS> Press then use <+> or <-> to increase or decrease speed or sensitivity
<R>, <G>, <B>,
<FADE/SNAP> Press to toggle between fade and snap programs
<MANUAL>
The RFC remote will not respond to any inputs when Freeze or Black Out is activated. If the remote
does not respond when a button is pressed, try pressing <FREEZE> or <BLACK OUT>. Freeze or
Black Out may have been inadvertently activated.
RFC Instructions Rev. 1
Button Function
Press to toggle strobe, then use <+> or <-> to increase or decrease strobe speed
<DIMMER> Press then use <+> or <-> to increase or decrease the dimmer
<AUTO> Press to activate automatic mode, then use <+> or <-> to select a program
<SOUND> Press to activate sound-active mode, then use <+> or <-> to select a program
Press to decrease speed, sensitivity, or the dimmer/color value, or to scroll down
<–>
the list of programs
Press to increase speed, sensitivity, or the dimmer/color value, or to scroll up the
<+>
list of programs
<FREEZE> Press to stop all movement and color chasing
In manual mode, press then use <+> or <-> to increase or decrease the red
<A>, <W>,
(<R>), green (<G>), blue (<B>), amber (<A>), white (<W>), or UV (<UV>) value.
<UV>
Press to activate manual mode
<PRESET/
Press to activate presets/colors, then use <+> or <-> to select a preset/color
COLOR>
<PAN> Press then use <+> or <-> to increase or decrease the pan value
<GOBO> Press then use <+> or <-> to increase or decrease the gobo value
<FOCUS> Press then use <+> or <-> to increase or decrease the focus value
<TILT> Press then use <+> or <-> to increase or decrease the tilt value
<ZOOM> Press then use <+> or <-> to increase or decrease the zoom value
<PRISM> Press then use <+> or <-> to increase or decrease the prism value
