EN Manual
Installation
Adjust light and bracket angle
1 Prepare the lamp
Prepare lamp, accessories and tools well
firstly.
Mount on the wall
1 Drill the holes
Please use the measure card to drill 2 holes
of Φ8mm with a spacing of 150mm.
Note: The recommended mounting height is 2-4 meters.
2 Adjust light angle
Use Allen wrench to loosen the light panel
and adjust it to the demanded lighting angle,
then fix the screw tightly.
2 Put plugs and screws in wall
Put the plugs and screws in to the wall.
3 Adjust bracket angle
Rotating the screw to loosen the bracket,
adjust it to the appropriate angle.
Put on flat surface
1 Place lamp on wall
Fix the lamp onto the wall with expansion
plugs and screws.
FlinQ Solar LED Floodlight 10W
4 Fix the screw
After adjusting the angle fix the screw tightly.
