EN
Label/Color
<MASTER
STROBE>
<BLINDER>
<FREEZE>
<BLACK OUT>
<Red>
<Amber>
<Yellow>
<Green>
<Blue>
<Cyan>
<Magenta>
<White>
<UV>
<MOVING HEAD>
<PAR>
<LASER>
<STROBE EFFECT>
<DERBY>
<COLOR>
<MOVEMENT>
<SPEED>
<GOBO>
<MACRO>
<PATTERN|SPEED>
<PATTERN>
<PRESET 1–6>
3
QUICK REFERENCE GUIDE
Type Function
Button Press to trigger/toggle all effects to strobe
Button Press to trigger/toggle blinder effect (all effects white at full output)
Button Press to toggle freeze (hold all output at the current setting)
Button Press to toggle black out
Button Press to toggle all output to red
Press to toggle all output to amber and to select a parameter when programming
Button
follow spot mode
Button Press to toggle all output to yellow
Press to toggle all output to green and to select a parameter when programming
Button
follow spot mode
Button Press to toggle all output to blue
Press to toggle all output to cyan and to select a parameter when programming
Button
follow spot mode
Button Press to toggle all output to magenta
Press to toggle all output to white and to select a parameter when programming
Button
follow spot mode
Button Press to toggle all output to ultraviolet
Press to activate moving heads, to set moving heads to default, and to
Button
deactivate moving heads
Button Press to activate pars, to set pars to default, and to deactivate pars
Button Press to activate laser control, to set lasers to default, and to deactivate lasers
Button Press to activate strobes, to set strobes to default, and to deactivate strobes
Press to activate derbies/kintas, to set derbies/kintas to default, and to deactivate
Button
derbies/kintas
Button Press to cycle through colors for the associated effect
Button Press to cycle through movement macros for moving heads
Button Press to cycle through speeds for the associated effect
Button Press to cycle through gobo effects for moving heads
Button Press to activate and cycle through macros for pars
Button Press to cycle through patterns/speeds for lasers
Button Press to cycle through patterns for strobes
Press and hold to save settings to the preset slot, then use the <X> encoder to
Button name the preset and assign a button color
Press to activate and deactivate the preset
