Control Panel Overview

Control Panel Description
Label/Color
<X>
<Y>
<FOLLOW SPOT>
<AUTO SPEED>
<SENSITIVITY>
<STROBE SPEED>
<MASTER
DIMMER>
<AUTO>
<SOUND>
ILS Command QRG Rev. 1
QUICK REFERENCE GUIDE
Type Function
Press to access menu, enable the currently displayed menu, or set the currently
selected value into the selected function
Encoder Press and hold for 3 seconds to lock and unlock the ILS Command
Rotate to navigate through the menu list, to increase or decrease numeric values
in a function, and to program the pan of moving heads for follow spot mode
Press to exit from the current menu or function
Press and hold for 3 seconds to lock and unlock the ILS Command except for the
Encoder
<PRESET> buttons
Rotate to program the tilt of moving heads for follow spot mode
Press to activate and deactivate follow spot mode
Press and hold to program follow spot mode positions, colors, and gobos
(Use the <amber>, <green>, <cyan>, and <white> buttons with the <X> and <Y>
Button
encoders to program)
Press and hold again to finish programming, then use the <X> encoder to save
or cancel
Fader Adjust to set the speed of automatic/preset programs and macros
Fader Adjust to set the sensitivity of the microphone or aux input in sound mode
Fader Adjust to set the strobe speed
Fader Adjust to set the master dimmer value
Button Press to activate automatic mode
Button Press to activate sound mode
