A.1.7.
Joystick VNS0-A for front fastening, drive A
Version with
• Plastic or aluminum escutcheon**
• Rubber boot S3*
• Adapter for encoder/potentiometer (A)
• Terminal block for HU contact possible (K)
See also section 4.4.4 "Joystick VNS0/NNS0 drive", page 66 and Appendix B. "Knobs and available fittings",
page 104.
M4
67
85
Figure 7.
Joystick VNS0-FM (dimensions in mm)
Dimension L1/L2 (mm)
Number of double contact elements
Table 13.
Joystick VNS0-FM – dimensions L1 and L2 (dimensions in mm)/number of double contact elements
Weight
Drive block
Per double contact element
Table 14.
Joystick VNS0-FM – weights
90
L1
A
40
55
1
~ 1.2 kg
~ 0.08 kg
70
180
145
110
K
70
85
100
2
3
4
5
115
130
145
160
6
7
8
9
Spohn & Burkhardt
175
10
