EN Manual
To disconnect
1. Go to the Bluetooth settings of the Bluetooth audio player.
2. Please select 'FlinQ Soundbar' in the list of devices and choose the option to disconnect.
Note: If the soundbar is connected to a Bluetooth audio player, you need to disconnect
first, before you can connect it to another device.
AUX Mode
1. After switching on the soundbar, change to AUX input mode.
2. Plug in the 3.5mm AUX cable to the AUX IN connector on the soundbar and put on your
favorite song immediately.
USB Mode
1. Plug in the USB drive.
2. The music in the USB drive will be played automatically. Please use the remote to control it.
3. The maximum support USB: 32GB.
Note: USB input mode is not available in the source selection. It will appear only after
inserting a compatible USB drive.
HD Mode
1. The soundbar supports HD with Audio Return Channel (ARC). If your TV is HD-ARC
compliant, you can hear the TV audio through the soundbar by using a single HD cable.
2. Using a High Speed HD cable, connect the HD TV (ARC) connector on the soundbar to the
HD ARC connector on the TV.
3. Please select HD (ARC) mode on your TV. For any details, see the TV user manual.
Note: the HD ARC connector on your TV might be labelled differently. For details, see the
TV user manual.
Optical Mode
Use an optical cableconnect to the optical connector on the soundbar to the optical out
connector on the TV or any other device.
Power-off Memory Function
1. When power on the device from standby mode, the device will remember last set up of
volume and bass and treble.
2. If you power on the decive (power cable reconnect again), the device will remember the
last setup of the bass&treble and the playing mode of the last setup. The volume will be
back at the factory default (18).
Specifications
Power
Sensitivity
Frequency response
Distortion
Bluetooth version
Bluetooth range
Display screen
Dimensions (with stand)
Dimensions (without stand)
Weight
Use your own TV remote
When you want to use your own TV remote to control your TV and the volume of the
soundbar please read the instructions below.
Via HDMI cable
Connect your soundbar to your TV with a HDMI cable. Make sure you place the HDMI cable
into the HDMI port with ARC function. The HDMI port without ARC will not work. Please
select the ARC function via the 'mode' button on the soundbar or the soundbar remote.
Note: In some cases you will need to change the sound settings on the television to make
this work.
Via Optical cable
Connect your soundbar to your TV with an optical cable. Please select the OPT function via
the 'mode' button on the soundbar or the soundbar remote.
Via AUX cable
Unfortunately it is not possible to use your TV remote to control the soundbar via AUX
cable.
FlinQ Soundbar Play
80W (total system power)
91dB
40 Hz-20k Hz
</=1% (1k/1w)
5.0
Up to 30 ft
LED
920 x 86 x 75 mm
920 x 86 x 66 mm
2.24 kgs
