Spectro-UV SPECTROLINE uVision-Serie Bedienungsanleitung Seite 3

MEASURING LAMP INTENSITY
To ensure that your uVision™ series lamp is operating at the required UV intensity, it should
be checked periodically. Spectro-UV offers a variety of sensors and meters. The AccuPRO™
ITEM QTY PART NO.
XP-2000 combines the functionality of a UV and visible light radiometer/photometer, and is
1A 1
specially designed to measure UV irradiance with wavelengths of 320–400nm (with peak
1B 1
at 365nm) and visible light from 460–675nm (with peak at 555nm). Other suitable meters 1C 1
1D 1
include the AccuMAX™ XRP-3000 radiometer/photometer kit, using dual-wavelength
BP 1
UV-A and VIS sensor detectors to accurately measure the irradiance of a light source. The
B
2 1
AccuMAX™ XR-1000 digital readout unit with the XS-365 UV sensor or the DM-365XA
3 1
digital readout unit can also be used for UV-A measurement. For more information about
4 3
these units, please contact the Customer Service Department at Spectro-UV. Call toll-free
5 1
1-866-230-7305.
KEY FEATURES
• 50 Foot (15 Meter) Retractable Power Cord Reel
• Nominal steady state intensity of 6,000 µW/cm
• Large 6.4-inch diameter coverage area at 15 inches (38cm) with a minimum UV-A
intensity of 1,200 µW/cm (ASTM E3022-15).
2
• Less than 1.0 foot-candle (11 lux) emission.
• Long-lasting UV-A lenses.
• Cool running, fanless design.
• Lightweight and rugged construction.
• White Light, LED Inspection Light.
• IP65 Rated: The uVision™ Series lamps are protected from total dust ingress and
from low pressure jets of water (from all directions). For more details, consult EN 60529
(British BS EN 60529:1992, European IEC 60509:1989).
• Certificate of Conformance (ASTM E3022-15) included.
A
TECHNICAL SPECIFICATIONS
uVision™ Series
UV-365HCR
Height
Length
Width
Weight
PROPERTY OF SPECTRONICS CORP; DO NOT DUPLICATE
Light Source
ELECTRICAL SPECIFICATIONS
Input: 100-240V AC, 0.9, 50-60 Hz
Output: 15V DC, 2.4A
POWER CORD SPECIFICATIONS
LAMP PART NUMBER
UV-365HCR
UV-365HCR/F
UV-365HCR/FA
UV-365HCR/FB
UV-365HCR/FBR
4
UV-365HCR REPLACEABLE PARTS LIST
DESCRIPTION
POWER SUPPLY, REEL, 50FT, UVISION, 120V, US
130405
POWER SUPPLY, REEL, 50FT, UVISION, 230V, EU
130406
130407 POWER SUPPLY, REEL, 50FT, UVISION, 240V, AU
130408 POWER SUPPLY, REEL, 50FT, UVISION, 230V, UK
FP-600 FILTER PROTECTOR ASSEMBLY
128196 FRONT COVER PLATE/ FILTER ASSEMBLY
128385 FRONT COVER GASKET
UV LED LENS, WITH ADHESIVE
129427
130336 LAMP HOUSING ASSEMBLY
at 15 inches (38cm).
2
UV-A (365nm) and white light
7.5 inches
4.25 inches
3.75 inches
15.45 lb. (including Reel and Power Supply)
3 UV-A LEDs, 1 white light LED
4
POWER REQUIREMENTS*
120V/50–60Hz
230V/50Hz
240V/50Hz
230V/50Hz
220-240V/50-60Hz
4
3
UV-365HCR EXPLODED VIEW
AND REPLACEMENT PARTS
BP 2 3 4
1A-1E 1A
1B
1C
1D
FILE NAME & PATH C:\Engineering\Projects\TRITAN\Ultravision 365\A-18103, UV-365HCR, ASSEMBLY, MANUAL.idw
MATERIAL
Replacement Parts
DIMENSIONAL TOLERANCES
UNLESS OTHERWISE SPECIFIED
ITEM QTY PART NO.
FRAC. DEC.
+ 1/64 +
.005
1A 1 130405 - -
1B 1 130406
SCALE NO. REQ'D
1C 1 130407
NEXT ASSY.
1D 1 130408
3
1E 1 130504
BP 1 FP-600
2 1 128196
3 1 128385
4 3 UL-110
5 1 130336
Accessories
QTY PART NO. DESCRIPTION
1 UVS-30 UV-ABSORBING SPECTACLES
2
5
FINISH
TITLE
DESCRIPTION
ANG.
UV-365HCR
+
30'
POWER SUPPLY, REEL, 50FT, UVISION, 120V, US -
MANUAL
POWER SUPPLY, REEL, 50FT, UVISION, 230V, EU
PHILIPC 11/8/2017
POWER SUPPLY, REEL, 50FT, UVISION, 240V, AU DRAWN DATE
CHECKED DATE
POWER SUPPLY, REEL, 50FT, UVISION, 230V, UK
APPROVED
DATE
2
POWER SUPPLY, REEL, 50FT, UVISION, 220-240V, BR
BOROFLOAT FILTER PROTECTOR ASSEMBLY
®
FRONT COVER PLATE / UV-A FILTER ASSEMBLY
FRONT COVER GASKET
UV LED LENS, WITH ADHESIVE
LAMP HOUSING ASSEMBLY
5
1
SPECTRONICS PART NO.
UV-365HCR
SPECTRONICS
CORPORATION
956 BRUSH HOLLOW ROAD
WESTBURY, NEW YORK 11590
SIZE
DRAWING NUMBER
RE
1
B
A-18103
1
