9
Navigate by tapping the touch screen to select an option or slide along a

HOME SCREEN

1.
2.
3.
4.
1. WiFi Indicator - Displays WiFi connection status
2. Directional Arrows - Moves material and machine head
3. Play Button - Resumes cut or recuts the last known design
4. Tool Reorientation - Moves tool holder back to starting position
5. Settings - Opens cutter settings menu
6. Cut Settings - Opens presets menu with adjustable cut settings
7. Test Cut - Performs a test cut at the tool holder's current position

HOME SCREEN JOB IN PROGRESS

1.
2.
1. Pause Button - Pauses job at current position
2. Job Progress Bar - Displays progress of current job based on how
far the circle is completed
3. Cancel Button - Cancels current job

TOUCH SCREEN

bar to adjust values.
5.
SETTINGS
6.
CUT SETTINGS
7.
TEST CUT
SETTINGS
CUT SETTINGS
TEST CUT
3.
