7 Installation
7.1 Factors affecting wireless signal strength
Surrounding objects can reduce the strength of the wireless signal:
■
Walls and reinforced concrete ceilings
■
Coated or vaporised insulating glass panes
■
Proximity to metallic and conductive objects (e.g., radiators)
■
Broadband interference, e.g. in residential areas (DECT phones, mobile phones, radio
headsets, wireless speakers, wireless weather stations, baby monitoring systems, etc.)
■
Electric motors, transformers, power-supply units and computers
■
Poorly shielded or uncovered computers or other electrical appliances
7.2 Selecting installation location
Before you install or place the product, select an installation location that meets safety and
operational requirements.
■
The installation location must not be hollow or where water can collect and enter the
product.
■
The installation location must be firm, horizontal, and even to ensure that rainwater can
run off without entering the product.
■
If Wi-Fi connectivity is required, the installation location must be within the range of the
Wi-Fi network.
7.3 Installing on soft surfaces
Use the ground spike to install the product on soft surfaces such as lawns.
Important:
Only install or place the product on a vertical and level surface.
1. (If connected) Disconnect the product from the power supply.
2. Position the product and check that the water drainage holes on the left and the right side
of the casing are not obstructed by any objects. If the drainage holes are obstructed,
change the location.
3. Screw the spike into the bottom of the product.
4. Insert the spike together with the product into the soft underground.
7.4 Installing on hard surfaces
Use the integrated mounting holes to install the product on a hard surface.
Important:
Only install or place the product on a vertical and level surface.
1. (If connected) Disconnect the product from the power supply.
2. Position the product and check that the water drainage holes on the left and the right side
of the casing are not obstructed by any objects. If the drainage holes are obstructed,
change the location.
3. Install the product using installation material suitable for the installation surface.

8 Operating

After you have installed the product, you can power appliances that are suitable for outdoor
use.
Important:
This product has an ingress protection rating of IP44 and is suitable for outdoor use. It is
"splash proof" and protected from objects greater than 1 millimeter in size and water
spray from any direction.
■
This rating is only effective if:
– The mains plug is connected to a power outlet rated IP44 or higher.
– An IP44 rated plug is connected to the socket(s) of the product --OR-- The socket
covers on the product are closed.
■
Do not use the product in areas where water accumulates.
1. Connect the mains plug to a suitable mains socket.
2. Switch off the appliance you intend to power with the product.
3. Connect the mains plug of the appliance to one of the sockets.
4. Guide the mains cable of the connected appliance through a recession in the product.
Make sure the mains cable does not get jammed when you close the cover of the hous-
ing.
5. On the product, push the On/Off button to supply power to the sockets.
6. After use, push the On/Off button to stop supplying power to the sockets.
Important:
If you control the product via the mobile app, use the On/Off button to manually override
the status of the sockets.
5
9 Setting up mobile app control
9.1 Adding the product to the mobile app
For mobile app control, you must add the product to the app and connect it to a suitable
Wi-Fi network.
Important:
The product can only be connected to 2.4 GHz Wi-Fi networks.
Preconditions:
a
The TUYA mobile app "Smart Life - Smart Living" is installed on your mobile device.
a
The product is within the range of the Wi-Fi network.
a
Your mobile device is near the product.
1. On your mobile device, activate Wi-Fi.
2. On your mobile device, activate Bluetooth and the location.
3. Connect your mobile device to the Wi-Fi network to which you intend to connect the
product.
4. In the centre of the product, hold down the On/Off push button until the indicator light
flashes.
5. Open the mobile app.
6. Tap on + to add a new product.
7. Tap on Auto Scan to find the new product.
8. Wait for the auto scan function to list the product.
9. Follow the on-screen instructions to add the product.
à
You have added the product to the mobile app and connected the product to the Wi-Fi
network.
à You can now control the product via the mobile app.
9.2 Controlling the product
After you have connected the product to the Wi-Fi network, you can control it remotely via
the mobile app.
A
B
A Controls the right sockets
10 Cleaning and care
Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2. Clean the product with a dry, fibre-free cloth.

11 Declaration of Conformity (DOC)

Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this
product conforms to the 2014/53/EU directive.
■
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Enter the product item number in the search box. You can then download the EU declaration
of conformity in the available languages.
B Controls the left sockets
