NETWORK CONNECTION

The XEDAI module from LD Systems enables remote control of compatible
devices, such as IPA Series amplifiers, via the network. Once the XEDAI module
is installed in a device, it can be connected to a network infrastructure and
controlled via a computer using LD Systems QUESTRA software.
PREREQUISITES FOR OPERATION
• Computer with QUESTRA software installed
• Network interface (router, switch) with activated multicast traffic
(activate IGMP protocol).
• Ethernet cable. Use a standard RJ45 Ethernet cable (Cat 5e or better)
for all wired connections.

FIRST STEPS

The XEDAI modules are delivered with a pre-configured static IP address
(192.168.0.192) as standard. To be able to recognise the unit with the Questra
software, please make sure that the IP settings of the computer on which the
Questra software is installed are configured in the same network range as the
XEDAI modules. See notes below.
• IP range : 192.168.0.X/24 (where X can be any value between 1 and 254, except
192 which is already used by default by the XEDAI modules)
• Network mask : 255.255.255.0
