Safety Information

Thank you for purchasing this product, please
read the manual carefully before operating,
and reserve it for future reference.
PRECAUTIONS
• Use only in a 12-volt DC negative-ground
electrical system.
• Disconnect the vehicle's negative battery
terminal while mounting and connecting
the unit.
• When replacing the fuse, be sure to use
one with an identical amperage rating.
Using a fuse with a higher amperage
rating may cause serious damage to the
unit.
• Make sure that pins or other foreign
objects do not get inside the unit, they
may cause malfunctions, or create safety
hazards such as electrical shock.
• If you have parked the car for a long
time in hot or cold weather, wait until the
temperature in the car becomes normal
before operating the unit.
• Keep the volume at a level at which you
can hear outside warning sounds (horns
sirens, etc.).
CAUTION
• DO NOT open covers and do not repair
yo ur se lf . Co n sult th e dea ler or an
experienced technician for help.

Specifications

General
Power supply: 12V DC (11V-16V)
Test voltage 14.4V,
negative ground
Maximum power output:
Suitable speaker impedance:
Weight:
Dimensions (WxHxD):
FM Stereo Radio
Frequency range: 87.5-108.0MHz(Europe)
Step: 50KHz(manual) 100KHz(automatically)
AM (MW) Radio
Frequency range: 522-1620KHz(Europe)
Step: 9KHz(manual) 9KHz(automatically)
AM (LW) Radio
Frequency range: 153-280 kHz(Europe)
Step: 1KHz(manual) 1KHz(automatically)
Usable sensitivity(S/N=20dB):
EXT (aux-in)
Jack Stereo 3.5mm ≥ 300mV auxiliary source
UK-1
Contents
Safety Information ..................... ..................1
Specifications ...............................................1
Panel Controls .............................................2
4X10W
Button Tips ...................................................3
4-8ohm
USB/SD MP3 Playback ................................4
1.0kg
182x53x112mm
USB/SD Notes.............................................4
Troubleshooting ............................................5
BEFORE OPERATION
• Do not raise the volume level too much,
as this will block outside sounds, making
driving dangerous.
• Stop the car before performing any
complicated operation.
Note:
30dBμ
1 According to models with different wiring
harness to connect the definition of the
specific content, please refer to the model
label.
2 Specifications and the design are subject to
change without notice due to improvements
in technology.
