10 Loudspeaker
11 Power supply
12 USB 2.0 interface
Note:
The serial port of the equipment is used for debugging only.
Installation
Install Host and Dock Station(s) to Bracket
No. Description
Screw installation
1 to 28
holes
Holes (2, 4, 7, 9) to
install screws for
29
one dock station
Holes (1, 3, 5, 6, 8,
10) to install screws
30
for two dock
stations
Holes (12, 14, 16,
18, 21, 23, 25, 27)
31
to install screws for
three dock stations
22 Body camera bin
Connection interface (to
23
connect the host)
No. Description
Holes (11, 13, 15, 17,
19, 20, 22, 24, 26, 28)
32
to install screws for four
dock stations
33 M6 stepped screw
34 M6 hand screw
7
English
