Back Panel

Dual AC Power
Site Environment
Keep the equipments indoors. If it is in rainy season or in humid environment, dehumidification
measures must be taken.
Ensure there is no water on the storage floor and no leakage to the packing box of the equipment.
Avoid automatic fire fighting facilities, heating system and other places where leakage may occur.
Installing
Installing Mounting Brackets
C49 C51
C53
C55
C57
C50 C52
C54
C56 C58
1. Secure the mounting brackets to the two sides of the open line system with 8x M3 screws.
PWR1
PWR2
LINE
C59
RX
DCN
TX
LOS FLT
LC
RX
TX
ACT PER
MON
C60
Reset
4 Fans
FAN
3
