6. Press 3 times on the black button on the back of your new motion sensor.
7. A message will appear: 'Product found'.
If the device is not found, press the 'Reset' button in the e-Centre's webpage and then
click the button on your motion sensor. After this procedure you can add the new
device correctly.
8. Give the new found device, the motion sensor you have just connected a name
and give a location, and click 'Save'.
9. The motion sensor has now been added to the e-Centre.
10. In most situations you want the motion sensor to activate the alarm when motion
is detected. Open therefore the webpage 'Setup alarmsensors'
11. Click on the alarm you wish to configure
12. Select your motion sensor under the list 'Not selected' and click then on the
arrow pointing to the right so that the motion sensor will be listed under the list
'Selected'.
13. Click on 'Save'.
14. Next time you enable the alarm, the motion sensor will trigger the alarm.

2.4 Choosing the optimal location for your motion sensor

1. The motion sensor should not be facing to a window, fan, airconditioner, open
mailbox or fax. Both direct and indirect sunlight can cause a false alarm.
2. Do not mount the motion sensor above a heat source, for example a radiator,
boiler or heater.
3. Place the EM6580 at a location where a trespasser walks by, instead of walking
straight towards the motion sensor. See figure 1.
Figure 1, sensor sensitivity
