Operating Instructions Glass Scourer GTW1200
Also applicable for Dish/Glass Scourer GTW1300 / GTW1700
Commissioning
Insert course sieve, surface sieves, wash arms
Assert free rotation of wash arms
Check supply of detergent and rinsing additive containers,
replenish as needed
Close door/hood
Press <KEY> (rapid flash LED green)
LED: Illuminated keys (red/green)
Note: Program selection possible only upon reaching
operational readiness.
Operational State: Status indication by <KEY> LED
Steady green: Ready for program selection.
Automatic Drainage: If unit is idle for 5 hours or more,
machine automatically drains and turns itself off.
GEHRIG
Operation
Load dish racks
Open door/hood and insert rack
Close door/hood
Press <KEY>
1x: Cups /Dishes
2x: Glasses
Status indication unit with <Key> LED
Standard: Press once (blinks 1x)
Short:
Press twice (blinks 2x).
Pre-selection with Standard (GTW 1700): Press 3x (blinks 3x).
At program end, automatically starts next program by
opening/closing door/hood.
Operating Modes: (Mixed service not possible)
Tank: Multiple use of tank water with fresh water post rinse (peak
load operation)
Water exchange: Corresponds with tank operation. At end of wash
program, machine is automatically drained and shut down (light
load operation)
Options
Automatic hood opening (GMS1700)
At program end, hood opens automatically. Closing is manual.
Significance of <KEY> per Unit Status
OFF:
Does not shine: Unit out of action
Launch: (Press 1x)
Rapid green flash: Launch operation in progress or missing
detergent/brightener (empty indication optional)
Operational Readiness:
Steady green: unit operational
Wash Programs: (press 1 to 3x)
Blinks 1x: Std. program for cups/dishes active
Blinks 2x: Short program for glasses active
Blinks 3x: Std. program with pre-selection active
Deactivation: (Keep pressed for 5 seconds)
Rapid green flash: drain program active
Subject to change without prior notice / 72094 / Applicable for SW 72107-V6
F. Gehrig AG / SA / Inc
CH-6275 Ballwil (Switzerland), Ph: +41 41 449 77 77, Fax: +41 41 449 77 76
GTW 1200 / 1300 / 1700
3x: Pre-selection
Daily Cleaning, Decommissioning
! Warning ! Unit must never be hosed down nor cleaned by
pressure washer.
Close door/hood
Press <KEY> for min. 5 seconds (LED blinks)
Wait until drainage complete (LED dims)
Open door/hood
Remove and clean lower wash arm and large surface sieves
Clean inside of tank. Remove foodstuff remnants, by sprinkler
head if needed (see residual water drainage).
Remove course sieve, clean and re-install
Close door/hood
Residual Water Drainage: With door/hood open, press key
<Wash Program long> for 5 seconds (drain time 2 min.)
Major Cleaning Maintenance (weekly)
See 'Daily Cleaning'
Remove jets/wash arm, clean and re-install
Clean exteriror of machine
If needed, empty and clean powder dosing unit
Descaling Unit (if needed)
See 'Commissioning'
Add descaler additive to tank content at specified concentration
(heed product notes)
Tank capacity: GTW1200-12 liters / GTW1300-15 liters /
GTW1700-26 liters
<Wash program long> run 2-5 times
Deactivate machine
Troubleshooting
Inadequate Cleaning
Has sieve been cleaned?
Are wash arms clean?
Are wash arms free to rotate?
Are additive storage levels OK?
Is suction hose immersed in storage container?
Have storage containers (detergent/brightener) inadvertently
been swapped?
Machine inoperable
Is main switch ON?
Is machine connected with power source (connector plug)?
Are building side fuses OK?
Is water valve open?
Does water remain in machine after drain cycle?
Is drain on building side clogged?
Remedy: Main switch OFF – wait 5 seconds – switch ON
If problems persist: Contact GEHRIG Customer Service
(Tel. N° 0 800 857 777) to report error code / problem
<KEY>
LED
GEHRIG
Hotel/Restaurant Industry and Home
