Push-Button; Wiring Example - LD Systems MIBS Bedienungsanleitung

5
The operating mode selector switch is located on the underside of the base.
PUSH TO TALK
PUSH TO MUTE
LATCH ON/OFF

WIRING EXAMPLE

Microphone
Microphone (not included)
(not included)
6
The microphone is only active as long as you press the
2
button . To mute the microphone, release the button.
The microphone is permanently active and is only muted
as long as the button

Push-button

2 with switch function. Press the button
briefly to activate the microphone and again briefly to
mute it.
Preamplifier / Mixing amplifier (not Included)
Microphone cable (not included)
Microphone cable
(not included)
2
is pressed.
Preamplifier / Mixing amplifier (not included)
