OPERATION MANUAL OF DDR, DDS TYPES DIAMOND DRILL BITS,
L=50-80 MM (DIAMOND ANNULAR DRILL BITS (САМК), DIAMOND
SEGMENTED DRILL BITS (САМС), L=50-80 MM) WITH COOLING
DEAR CUSTOMER!
Thank you for choosing products of DI-STAR company! The high quality of raw ma-
terials and other materials, the correct choice of components, the use of modern tech-
nologies, as well as precise control make our product worthy of using it for a long time.
To guarantee all of the following, please follow the recommendations found in this
brochure. This is the only way you can maintain the quality of your DI-STAR company di-
amond tools.
TOOLS CLASSIFICATION
It's the professional
diamond tools with a good
combination of price -
resource - performance. A
series of universal use for
professional work, mainly
household area.
PURPOSE OF USE
Diamond drill bits of the DDR, DDS type L=50-80 mm (САМК, САМС L=50-80 mm) are
designed for drilling artificial and natural construction materials by a manual power tool with
the obligatory use of cooling (see Table 2, "Abrasiveness of materials").
Drill bits of the DDR, DDS type L=50-80 mm (САМК, САМС L=50-80 mm) are made
with following types of mounting (for the works on the equipment):
1) With shank drill d12 for manual electric drilling with a power of 0.8-1.5 kW with a
rotational speed of 800-1500 rpm in drilling shear mode;
2) With inner mounting M14 for drilling with the using of a manual angle grinder with
a power of 0.8-1.5 kW with a rotational speed of 2800-4000 rpm.
EN
Professional diamond tools
with the best combination
of resource - productivity -
specific processing costs.
The series is designed for
large volumes of diamond
cutting by professional
users.
The TOP class professional
diamond tools that meet
the highest requirements.
Specialized professional
series aimed at meeting
the needs of the industrial
market.
