ASSEMBLY INSTRUCTION
#5
#70
Step 2.
• Remove the 4 x Head Hex Socket Screws (17) in the end of the Left Stand Tube
and Right Stand Tube.
• Attach the Handlebar (70) onto both ends of the Stand Tube, tighten the screws
with the Allen Key provided.
• Connect the wire that comes from the Computer Console (5) to the Main Control
Cable Socket from the right handlebar support of the Right Stand Tube.
• Install both Handlebar Covers (19) onto the Handlebar (70).
#19
#17
(cont.)
Main Control
Cable Socket
