SPI-VLOGYG
OIL-GLO ULTRA Complete Fluorescent Leak Detection Kit
®
For Use in Industrial Synthetic and Petroleum-Based Fluid Systems
Quickly finds leaks in enclosed circulating systems containing fluids that are miscible with oil
(petroleum or synthetic-based), fuel, lubricant or similar fluids. For best leak detection results, use
OIL-GLO ULTRA dye with a Spectroline
®
For best inspection results, use a high-intensity Spectroline
and wear fluorescence-enhancing glasses to protect your eyes and to make leaks clearly visible.
Lamp Operation
z To operate the SPI-VL Violet Light LED Leak Detection
Lamp: Insert 3 AAA batteries (included). Press the button
in the end cap once to turn the lamp on. Press it again to
turn the lamp off.
z To Replace Batteries: Twist the end cap
counterclockwise to open. Remove the battery carousel.
Directions
1. Add the appropriate OIL-GLO
system. Begin with the recommended dilution ratios of dye
to host fluid. More dye can be added to the system if leaks
are not clearly visible.
2. Run the system to allow the OIL-GLO
circulate thoroughly. The dye needs time to mix with the
oil and circulate to all the leak sites. This period of time
will vary greatly depending on the size of the system and
the size of the leak. It could take anywhere from 5 to 10
minutes for small systems with large leaks, to several days
for larger systems with smaller leaks.
3. Inspect all areas with a high intensity Spectroline
Be sure to use the fluorescence-enhancing glasses
supplied with the lamp. In hard to reach areas, use a
mirror to reflect the light, or wipe the obstructed area with
a clean cloth, and then check for the fluorescence. NOTE:
For best results, use the lamp in low-light conditions.
Kit Contents
Part No.
SPI-OGYG-8
SPI-VL
RP-GA-2
RP-UVS-40
N/A
READ CAUTIONS AND DIRECTIONS BEFORE USING.
FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY.
IMPORTANT!
ULTRA dye to the suspect
®
® ULTRA dye to
lamp.
®
Description
Patented 8 oz (237 ml) twin-neck bottle of concentrated oil dye (glows yellow-green).
Treats up to 64 gallons (242 L) of fluid.
Violet light LED, battery operated leak detection flashlight
2 oz (60 ml) spray bottle of GLO-AWAY™ PLUS dye cleaner
Fluorescence-enhancing glasses
Dye treatment tags
leak detection flashlight in low-light conditions.
®
ultraviolet or violet light leak detection lamp
®
Insert 3 AAA batteries and reinstall the carousel (positive
end toward the lamp head). Replace the end cap.
z Warranty:
To review the warranty policy:
4. OIL-GLO ULTRA can safely remain in the system, so you
®
can check the repair without adding more dye.
5. After the leaks are repaired, clean the leak sites with
Spectroline GLO-AWAY™ PLUS dye cleaner or a shop
®
cleaner. Check with the lamp to be sure all dye residue is
removed. Residual dye could give a false leak indication.
6. Run the system again and reinspect with the lamp. No
glow means all leaks have been fixed!
2
en
spectroline.com/warranty
