INSTALLATION INSTRUCTIONS
Fixed colour palette*:
By setting a value between
700 – yellow
701 – cyan
702 – green
703 – magenta
704 – red
705 – blue
706 – turquoise
707 – orange
708 – white (rgb)
709 – white (rgbw)
710 – white (just w)
Show*:
By setting a value between
711 – RGBW show (5 sec transition, 5 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta+W, white, yellow+W
712 – cool colours show (10 sec transition, 2 sec dwell time)
cool white, cyan, blue
713 – warm colours show (10 sec transition, 2 sec dwell time)
warm white, orange, yellow
714 – RGB show (20 sec transition, 5 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
715 – RGBW show (10 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
716 – RGB show (5 sec transition, 2 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
717 – RGBW show (40 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
718 – RGBW show (20 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
719 – RGB show (40 sec transition, 2 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
720 – rapid RGB show (2 sec transition, 2 sec dwell time)
red, green, blue
*Using the push buttons with fixed colour palette and shows:
In the two previous cases (with the Contraves devices set between
to the next step as if increasing the value selected by the Contraves devices by one unit: the cycle includes all fixed colour pal-
ettes and shows regardless of which of the two modes you started from. With this functionality, the value given by the Contraves
devices only establishes the initial step (colour/show).
A long press on push button 2 increases or decreases the intensity of the output, while pressing push button 1 for about 1.5
seconds switches off the driver's outputs. These can be reactivated with a short press of the same button.
When switched back on, the default colour/show and intensity are restored.
Control using two push buttons to drive all the outputs:
Setting a value between
the intensity of all outputs in parallel.
