PURPOSE
Determination of body temperature of persons
TURNING ON THE THERMOMETER
The device must be installed and put into operation
in accordance with the instructions in this manual.
To get help concerning usage or maintenance please
contact your dealer or the manufacturer.
An unexpected operating condition or an incidence
which has worsened the health condition or could
have worsened the health condition should be repor-
ted to the manufacturer immediately.
To turn on the thermometer, push the ON/OFF-button;
a short signalling tone [beep] indicates «thermometer
ON.» A so-called LCD-test automatically takes place
to check the display. Then a «Lo» and a flashing «°C»
appear on the upper right of the display, if the ambient
temperature is less than 32°C. Now the thermometer
is ready for use.
USING THE THERMOMETER
During a measurement, the temperature is displayed
continuously and the «°C» symbol flashes. If the sig-
nalling tone sounds (beep-beep-beep-beep 10 times)
and the «°C» no longer flashes the measurement is
completed (the measured increase in temperature is
now less than 0,1 °C in 15 seconds).
To extend the lifetime of the battery, turn off the
thermometer after usage by pressing the ON/OFF-
button briefly. Otherwise the thermometer will auto-
matically turn off after about 10 minutes.
MEMORY OF MEASURED VALUES
When turning the thermometer on, the temperature
of the last measurement will be displayed. After 3
seconds, this value will disappear and the thermo-
meter will switch to the normal measurement mode.
Then the stored value is erased.
CLEANING AND DISINFECTING
For cleaning of the instrument please use isopropyl
alcohol (70%). For disinfecting wipe the instrument
completely with Antifect Liquid (please obey 5 min.
work-in-time).
CHANGE OF BATTERY
As soon as the symbol „
the battery is weary and a new battery has to be
inserted. Open the cover of the battery compartment
and insert the new battery with „+"symbol facing
upwards.
If the device is not used for an extended period (4
weeks or more), remove the battery in order to pre-
vent any damage that may be caused by leakage.
.
" appears on the display,

TECHNICAL SPECIFICATIONS

Maximum thermometer
Measuring range: 32.0°C to 42.9°C
Temp.< 32.0°C:display «Lo» for low (too low)
Temp.> 42.9°C:display «H» for high (too high)
Accuracy: ± 0.1°C between 35,5°C and 42,9°C
Operating conditions: environmental temperature 5°C
to 35°C, air pressure 700 – 1060 hPa, relative humidity
40 to 80%
Liquid crystal display (LCD) with three digits. Smallest
unit of display: 0.1°C
Signalling tone sounds when thermometer is ready for
use and when measurement is completed.
Memory: automatic memory of the last measured
value.
Storage conditions: environmental temperature
-25°C to +55°C, relative humidity 15% - 95%
Battery: 1,5 V, IEC-Type LR/SR41
1,000 measurement cycles (depending on frequency
of use).
Norm: ISO 80601-2-56, Particular requirements for
basic safety and essential performance of clinical
thermometers for body temperature measurement
Protection against solid objects and water: IP 67 (in
accordance with IEC 60529)
Expected operational lifetime of the equipment: 10
years
WARRANTY
This unit is under warranty for 2 years from the date
of purchase.
Please submit the receipt, invoice or delivery note
when claiming for warranty.
For both, warranty and repair, please send the instru-
ment carefully packed and postage paid either to your
authorized dealer or directly to
Bosch + Sohn GmbH und Co. KG
Bahnhofstraße 64,
72417 Jungingen – Germany
Warranty and repair work must be undertaken by
trained and authorised personnel. Do not modify this
equipment without authorization of the manufacturer.
CARE FOR THE ENVIRONMENT
Used batteries and defective electronic devices do
M
not belong into the household waste.
They can be deposited at special centres. Please con-
tact your local authorities for information.
LOT
Bosch + Sohn GmbH und Co. KG
Bahnhofstraße 64 · 72417 Jungingen · Germany
Tel.: +49 (0) 7477/9275-0 · Fax: +49 (0) 7477/1021
www.boso.de · service@boso.de
