SPECIFICATIONS
Voltage
Maximum Air Volume
Maximum Air Velocity
Maximum Blower Force
Recommended Operating
Temperature
Recommended Storage
Temperature
Blower Weight
(Without battery with tube)
Measured sound power level L
WA
Sound pressure level at
operator's ear L
PA
Guaranteed sound power
level L
WA
(according to 2000/14/EC)
Vibration a
h
◾
The declared vibration total value has been measured
in accordance with a standard test method and may be
used for comparing one tool with another;
◾
The declared vibration total value may also be used in
a preliminary assessment of exposure.
NOTICE:
The vibration emission during actual use of the
power tool can differ from the declared value in which the
tool is used; In order to protect the operator, user should wear
gloves and ear protectors in the actual conditions of use.
PACKING LIST (FIG. A1)
DESCRIPTION
KNOW YOUR BLOWER (Fig. A1 & A2)
1. Handle
2. Battery-Release Buttons
3. Latch
4. Electric Contacts
5. Assist Handle
6. Air Inlet
7. Bellows
56 VOLT LITHIUM-ION CORDLESS BACKPACK BLOWER — LBP8000E
8. Control-handle Tube
9. Blower Tube
10. Control Handle
56 V
11. Backpack Plate
1360 m 3 /h
12. Blower-tube Storage Knob
85 m/s
13. Adjustable Support Harness
26 N
14. Tapered Nozzle
15. Cruise Control Button
-15°C-40°C
16. LCD Screen
-20°C-70°C
17. Turbo Button
18. Trigger Switch
7.4 kg
19. Tube-hanging Groove
20. Quick-release Lever
97 dB(A)
21. Fuel Gauge
K=1.2 dB(A)
22. Fan Icon
86.2 dB(A)
23. Turbo Indicator
K=2.5 dB(A)
24. Air-speed Indicator
25. Cruise Control Icon
98 dB(A)
26. Battery Icon
0.4 m/s
2
K=1.5 m/s 2
understanding of the information on the tool and in this
instruction manual as well as knowledge of the project
you are attempting. Before use of this product, familiarize
yourself with all operating features and safety rules.
ASSEMBLY
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
or create accessories not recommended for use with this
blower. Any such alteration or modification is misuse and
could result in a hazardous condition leading to possible
serious personal injury.
could cause serious personal injury, always remove the
batteries from the tool when assembling parts.
ASSEMBLING THE BLOWER TUBES
Connecting the Control-handle Tube Assembly to
the Bellows (Fig. C)
1. Insert the upper end of the control-handle tube into the
bellows as far as it will go.
WARNING:
The safe use of this product requires an
WARNING:
If any parts are damaged or missing,
WARNING:
Do not attempt to modify this product
WARNING:
To prevent accidental starting that
