Connecting the EL-9900 to the PC

Connect the EL-9900 to the PC with the supplied communication cable.
NOTE: Push in all connectors firmly and make sure they cannot be removed by pulling
them lightly.
Also tighten the fixing screws.
1. Turn off the EL-9900 and the PC.
2. Connect on side of the supplied communication cable to the peripheral connect-
ing terminal (communication port) on the bottom of the EL-9900; the other side to
the serial port of your PC.
communication cable(supplied)
6
Peripheral connecting terminal
To PC serial port
9 pin
