Longitude Angle: Set the longitude angle in USALS.
● ●
Latitude Dir: Set the latitude direction in USALS.
● ●
Latitude Angle: Set the latitude angle in USALS.
● ●
Language: Set the menu language.
● ●
Factory Default: Restore the product to the factory default.
● ●

4.10 Meter_Info

Home-> Meter_Info
In this menu, you can get the information about the Meter, such as
Product Name, Software version, Software Date, Serial Number.
Press the SAT/TP/TOOL button to turn off or on the lamp.
● ●
Press the METER button to show the professional measurement
● ●
menu.
30 English manual Xsarius Satmeter HD Easy Pro
IV. Additional Information
5.1 Technical Specification
Satellite Tuner & Demodulator
Frequency Range
Input Connector
Signal level
LNB supply
LNB switch control
DiSEqC
Symbol rate
Spectral inversion

5.2 Glossary

Antenna
● ●
A device that collects and radiates electromagnetic waves.
MHz
● ●
The prefix megameans million, and Hertz means cycles per
second.
Transponder
● ●
An automatic device that receives amplifies and retransmits a
signal on a different frequency antenna during the adjustment and
installation of the antenna. For own security, use a rope on sloping
roofs.
© Copyright 2018 A.D. B.V.
950MHz-2150MHz
male
-65dBm~-10dBm
13/18V,max 350mA
22KHz
DiSEqC 1.0 /1.1 / 1.2
2Mbps~45Mbps
Auto conversion
English manual 31
